WAGO DIN-rail fuse terminal block FUS1000
WAGO
WAGO DIN-rail fuse terminal block FUS1000
Home > WAGO > Terminal Blocks > FUS1000 Need WAGO FUS1000? DIN-rail fuse terminal block for Photovoltaic and industrial DC circuits up to 1000 V. Supp…
Specifications
| Brand | WAGO |
|---|---|
| Model Number | FUS1000 |
| Official Product Name | High Voltage Fuse Terminal Block (1000 V, DIN-rail) |
| Applicable System | Photovoltaic and industrial DC circuits up to 1000 V |
| Product Type | DIN-rail fuse terminal block |
| Equivalent Standard | IEC/EN 60947 (fuse terminal blocks) |
| Product Status | In Stock |
| Rated Voltage | 1000 V DC |
| Rated Current | up to 32 A (variant dependent) |
| Fuse Size | 10 x 38 mm or 5 x 20 mm (variant dependent) |
| Connection Technology | CAGE CLAMP / push-in |
| Wire Size | 2.5–16 mm² (AWG 14–6, variant dependent) |
| Mounting | DIN-35 rail (35 x 15 / 35 x 7.5) |
| Flammability Class | UL94 V0 |
| Blown Fuse Indication | Available on request |
| Insulating Material | Polyamide (PA66) |
| Product Type | Fuse terminal block (1-pole, 2-conductor) |
Product Description
WAGO's 1000 V rated fuse terminals, for example the 811 series midget 10 x 38 mm holders and the TOPJOB S 1000 V fuse terminal family, use CAGE CLAMP spring pressure connection technology and are designed for photovoltaic and industrial DC applications. Depending on the variant they accept 10 x 38 mm or 5 x 20 mm fuses and mount on standard 35 x 15 and 35 x 7.5 DIN-rail. Because FUS1000 is a pooled and descriptive designation, the exact WAGO item number should be confirmed from the terminal label. The WAGO FUS1000 is a high-voltage fuse terminal block for 1000 V DC circuits within WAGO's DIN-rail fuse terminal range.
Basic Product Information
- CAGE CLAMP spring pressure connection technology
- DIN-rail mounting for 35 x 15 and 35 x 7.5 rail
- Available with or without blown-fuse LED indication
- Suited to photovoltaic and industrial DC applications
- Rated for 1000 V DC high-voltage circuits
Technical Specifications
Version & Model Difference
WAGO's 1000 V rated fuse terminals span several families, including the 811 series midget fuse holders (750 V AC / 1000 V DC, up to 30 A) and the TOPJOB S fuse terminal blocks. The exact catalogue number depends on pole count, fuse size and indication option, so FUS1000 should be matched to the item number printed on the terminal.
Application Scenarios
- Overcurrent protection in photovoltaic DC strings
- Industrial DC control and distribution circuits
- Machine and panel protection of 1000 V DC loads
- DIN-rail terminal assembly in electrical cabinets
- WAGO FUS782000 Rail-Mount Fuse Terminal Block (782 Series, 6 mm2)
- WAGO FUS780500 Rail-Mount Fuse Terminal Block (780 Series, 2.5 mm2)
- WAGO 780-500 780 Series Rail-Mount Terminal Block Jumper
- WAGO 781-000 2-Conductor Ground Terminal Block
- WAGO 750-453/200-000 4-Channel Analog Input Module (750-453/200-000)
- WAGO 750-559/200-000 2-Channel Analog Input Module
Frequently Asked Questions
What is the WAGO FUS1000?
It is a high-voltage fuse terminal block rated for 1000 V DC, part of WAGO's DIN-rail fuse terminal range.
What fuse size does it accept?
Depending on the variant it accepts 10 x 38 mm midget fuses or 5 x 20 mm miniature fuses.
How is it connected?
It uses CAGE CLAMP spring pressure connection technology for 2.5–16 mm² conductors, variant dependent.
Where is it typically used?
In photovoltaic and industrial DC circuits up to 1000 V where fuse protection on DIN rail is required.
