WAGO Analog Input Module 750-559/200-000
WAGO
WAGO Analog Input Module 750-559/200-000
Home > Products > WAGO > Analog Input Modules Need WAGO 750-559/200-000? Analog Input Module for WAGO-I/O-SYSTEM 750. Supplied with full traceability …
Specifications
| Brand | WAGO |
|---|---|
| Model Number | 750-559/200-000 |
| Official Product Name | 2-Channel Analog Input Module, 0-10 V DC, 16-bit, Conformally Coated |
| Applicable System | WAGO-I/O-SYSTEM 750 |
| Product Type | Analog Input Module |
| Equivalent Standard | IEC 61131-2 |
| Product Status | In Stock |
| Signal Type | Voltage (0-10 V DC) |
| Resolution | 16-bit (15 bit + sign) |
| Conversion Time | 10 ms per channel |
| Input Impedance | > 1 MΩ |
| Measurement Error | ±0.1% of full scale (at 25°C) |
| Supply Voltage (System) | 5 V DC via system supply |
| Supply Voltage (Field) | 24 V DC via field supply |
| Current Consumption (System) | Typically 40 mA |
| Current Consumption (Field) | Typically 10 mA |
| Isolation | 500 V system/field |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (W x H x D) | 12 mm x 64 mm x 100 mm |
| Weight | Approx. 50 g |
| Approvals | CE, UL, ATEX (with appropriate coupler) |
| Number of Channels | 2 (differential) |
Product Description
It accepts voltage signals in the range of 0 to 10 V DC and provides 16-bit resolution for precise measurement. The module features a 2-wire connection for each channel and is compatible with the WAGO 750 series I/O system, which supports fieldbus-independent communication via the WAGO-I/O-SYSTEM. This module is equipped with a differential input, allowing for accurate signal acquisition even in noisy environments. The 750-559/200-000 variant includes a special coating (conformal coating) that protects the electronics from dust, moisture, and other environmental contaminants, making it suitable for harsh industrial conditions. The module's update time is typically 10 ms per channel, ensuring fast response for control applications. With its compact design, the module can be easily mounted on a DIN rail and is powered via the system supply (5 V DC) and field supply (24 V DC). It supports a wide operating temperature range from -20°C to +60°C, making it versatile for various industrial settings. The module is CE and UL approved, ensuring compliance with international standards. The WAGO 750-559/200-000 is a 2-channel analog input module designed for industrial automation systems.
Basic Product Information
- 16-bit resolution for high precision
- Differential inputs for noise immunity
- Conformal coating for protection against environmental contaminants
- 2-wire connection for each channel
- Update time of 10 ms per channel
- Compatible with WAGO-I/O-SYSTEM 750 fieldbus couplers
- Operating temperature range: -20°C to +60°C
- 2 analog input channels for 0-10 V DC signals
Technical Specifications
Version & Model Difference
The 750-559/200-000 is a variant of the standard 750-559 module with conformal coating (indicated by '/200-000'). The standard 750-559 does not have this coating. The conformal coating provides enhanced protection against moisture, dust, and chemical contaminants, making the module suitable for harsh environments. Other versions may include different signal ranges (e.g., 0-20 mA) or different resolutions, but the 750-559/200-000 specifically offers 0-10 V DC input with 16-bit resolution.
