Siemens Sensor Module 6sl3055-0aa00-4ba0
Siemens
Siemens Sensor Module 6sl3055-0aa00-4ba0
Home > Products > Siemens > Sensor Module Need Siemens 6sl3055-0aa00-4ba0? Sensor Module for SINAMICS S120 Drive System. Supplied with full traceabili…
Contact us for current availability and best price of 6sl3055-0aa00-4ba0.
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6SL3055-0AA00-4BA0 |
| Official Product Name | SINAMICS SMC30 Sensor Module |
| Applicable System | SINAMICS S120 Drive System |
| Product Type | Sensor Module / Encoder Interface Module |
| Equivalent Standard | DRIVE-CLiQ interface, TTL/HTL encoder compatible |
| Product Status | In Stock |
| Encoder Interface | 2 x encoder inputs (TTL/HTL) |
| Signal Levels | TTL (RS422), HTL |
| Communication Protocol | DRIVE-CLiQ |
| Supply Voltage | 24 V DC via DRIVE-CLiQ |
| Current Consumption | Max. 0.5 A |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -25 °C to +70 °C |
| Dimensions (W x H x D) | Approx. 25 x 125 x 105 mm |
| Weight | Approx. 0.2 kg |
| Mounting | Option Slot in SINAMICS S120 Control Unit |
| Protection Class | IP20 |
| Product Type | Sensor Module (SMC30) |
Product Description
It converts standard incremental encoder signals (TTL and HTL) into the DRIVE-CLiQ communication protocol, allowing motors and encoders to interface seamlessly with SINAMICS S120 and related drive systems. This module is essential for closed-loop speed and position control in high-precision industrial applications. The SMC30 module supports both TTL (RS422) and HTL (HTL/TTL) encoder types, with selectable voltage levels and signal monitoring. It provides two encoder interfaces, enabling dual-encoder configurations for applications requiring redundant or secondary feedback. The module is mounted on the drive's Option Slot and is hot-pluggable, which simplifies maintenance and system expansion. Its compact design and robust construction make it suitable for demanding industrial environments. Typical applications include machine tools, packaging machinery, printing presses, and textile equipment where accurate motion control is critical. The 6SL3055-0AA00-4BA0 is part of the SINAMICS S120 modular drive system, known for its flexibility and scalability. As a genuine Siemens OEM component, it ensures reliable performance and compatibility with other SINAMICS components, reducing commissioning time and downtime. The Siemens 6SL3055-0AA00-4BA0 is a SINAMICS SMC30 sensor module designed for encoder signal evaluation within the SINAMICS drive family.
Basic Product Information
- Two encoder interfaces for dual-encoder configurations
- Supports incremental encoders with RS422 (TTL) and HTL signal levels
- Hot-pluggable design for easy installation and replacement
- Integrated signal monitoring and diagnostics via DRIVE-CLiQ
- Compact module for Option Slot mounting in SINAMICS S120 drives
- Converts TTL and HTL encoder signals to DRIVE-CLiQ protocol
Technical Specifications
Version & Model Difference
The 6SL3055-0AA00-4BA0 is a specific variant of the SMC30 sensor module. Different versions may exist with variations in firmware or hardware revisions, but the core functionality remains the same. It is compatible with SINAMICS S120 Control Units and can be used with a wide range of encoders. For detailed version information, refer to the Siemens catalog or technical documentation.
Application Scenarios
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is the function of the Siemens 6SL3055-0AA00-4BA0?
It is a sensor module (SMC30) that converts TTL/HTL encoder signals to DRIVE-CLiQ for use with SINAMICS S120 drive systems.
Which encoders are compatible with this module?
It supports incremental encoders with TTL (RS422) and HTL signal levels. Both single and dual encoder configurations are possible.
Can this module be used with SINAMICS G120 drives?
No, the SMC30 is designed for SINAMICS S120 systems. For G120, different encoder modules are required.
Is the module hot-swappable?
Yes, the SMC30 is hot-pluggable, allowing replacement without shutting down the entire drive system, although proper safety procedures should be followed.
Need 6sl3055-0aa00-4ba0?
Get a Quote in Minutes.
12-month warranty · No MOQ · Worldwide shipping with tracking
Request a Quote
Get the latest price, stock status and bulk order discount for 6sl3055-0aa00-4ba0. Our team replies within 30 minutes (working hours).
