['Home', 'Siemens Spare Parts', 'SIMOVERT MASTERDRIVES', '6SE7090-0XX84-0FF5'] Need Siemens 6se7090-0xx84-0ff5? Option …
Contact us for current availability and best price of 6se7090-0xx84-0ff5.
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6SE7090-0XX84-0FF5 |
| Official Product Name | CBP2 communication board, PROFIBUS DP V1, for SIMOVERT MASTERDRIVES and SIMOREG DC-MASTER converters |
| Applicable System | SIMOVERT MASTERDRIVES 6SE70 / 6SE71 and SIMOREG DC-MASTER 6RA70 converters; referenced for 6SG70 stator voltage controller applications |
| Product Type | Option board (communication board) |
| Equivalent Standard | PROFIBUS DP V1 per IEC 61158 / IEC 61784 |
| Product Status | Discontinued / Legacy (MASTERDRIVES and SIMOREG platforms retired; spare parts only) |
| Board type | CBP2 communication board (PROFIBUS DP V1) |
| Fieldbus | PROFIBUS DP V1 (slave) |
| Data rate | 9.6 kbit/s to 12 Mbit/s |
| GSD files | masterdrives_cbp2, dcmastercbp2dpv1 |
| Mounting | Option slot of the converter electronics (MASTERDRIVES CUVC / CUR, SIMOREG CUD1) |
| Dimensions and weight | N/A |
| Supply | Powered from the converter electronics backplane (no external supply required) |
| Order number | 6SE7090-0XX84-0FF5 |
Product Description
Installed in the option slot of the converter electronics, it connects the drive to a PROFIBUS DP network as a DPV1 slave with cyclic and acyclic data exchange at rates from 9.6 kbit/s to 12 Mbit/s. The board is identified in PROFIBUS networks by the GSD files masterdrives_cbp2 and dcmastercbp2dpv1, which show the module type as 6SE7090-0XX84-0FF5. Siemens support documentation also references this board for 6SG70 stator voltage controller applications. It is a discontinued legacy option board supplied on inquiry. The Siemens 6SE7090-0XX84-0FF5 is the CBP2 communication board, a PROFIBUS DP V1 option board for SIMOVERT MASTERDRIVES (6SE70 / 6SE71) and SIMOREG DC-MASTER converters.
Basic Product Information
- Cyclic and acyclic DPV1 data exchange for parameterization, diagnostics and process data
- Data rates from 9.6 kbit/s up to 12 Mbit/s on standard PROFIBUS networks
- Plug-in option slot mounting in the converter electronics, no converter rework required
- Identified by the GSD files masterdrives_cbp2 and dcmastercbp2dpv1 in PROFIBUS engineering tools
- CBP2 option board providing PROFIBUS DP V1 slave connectivity for MASTERDRIVES and SIMOREG converters
Technical Specifications
Version & Model Difference
['CBP2 is the PROFIBUS DP V1 member of the MASTERDRIVES option board family; sibling boards cover other protocols such as CANopen (CBC) and DeviceNet (CBD) with different order numbers.', 'The board is catalogued under the 6SE7090-0XX84 option board block; the suffix 0FF5 identifies the PROFIBUS DP V1 protocol variant.', 'In PROFIBUS engineering tools the GSD short name appears as masterdrives/dcmastercbp2dpv1 while the module type displays the full order number 6SE7090-0XX84-0FF5.']
Application Scenarios
- Integration of MASTERDRIVES converters into PROFIBUS DP automation networks
- PROFIBUS DP V1 acyclic diagnostics and parameterization of installed SIMOREG DC drives
- Retrofit of communication options on legacy 6SE70 and 6RA70 converters
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is the Siemens 6SE7090-0XX84-0FF5?
It is the CBP2 communication board, a PROFIBUS DP V1 option board for SIMOVERT MASTERDRIVES and SIMOREG DC-MASTER converters.
How does the board appear in PROFIBUS engineering tools?
The board is described by the GSD files masterdrives_cbp2 and dcmastercbp2dpv1. After installing the GSD file, the module type is displayed as 6SE7090-0XX84-0FF5.
Which converters accept this board?
It plugs into the option slot of MASTERDRIVES converters with CUVC or CUR electronics and of SIMOREG DC-MASTER converters with CUD1 electronics. Siemens documentation also references it for 6SG70 stator voltage controller applications.
Is this board still available new?
No. Both the MASTERDRIVES and SIMOREG platforms are retired, so the CBP2 board is supplied as legacy spare part from surplus or refurbished stock. Request a quote for availability, condition and warranty.
