6SL3310-1TE33-1AA3
Siemens Active Line Module 6SL3310-1TE33-1AA3
Siemens
Siemens Active Line Module 6SL3310-1TE33-1AA3
Home > Products > Siemens > Active Line Module Need Siemens 6SL3310-1TE33-1AA3? Active Line Module for SINAMICS S120. Supplied with full traceability …
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6SL3310-1TE33-1AA3 |
| Official Product Name | Active Line Module (ALM) for SINAMICS S120 |
| Applicable System | SINAMICS S120 |
| Product Type | Active Line Module |
| Equivalent Standard | IEC 61800-4 |
| Product Status | In Stock |
| Rated Current | 490A |
| Supply Voltage | 380-480V AC (3-phase) |
| DC Link Voltage | 600-750V DC |
| Overload Capability | 150% for 60s, 110% for 120s |
| Communication Interface | DRIVE-CLiQ |
| Degree of Protection | IP20 |
| Cooling Method | Internal air cooling |
| Dimensions (W x H x D) | 300mm x 500mm x 300mm (approx.) |
| Weight | Approx. 45kg |
| Operating Temperature | 0°C to +40°C (derating above 40°C) |
| Standards | CE, UL, cUL, EAC |
| Rated Power | 310kW |
Product Description
With a rated power of 310kW at 380-480V AC, this module provides a controlled DC bus voltage, enabling energy recovery back to the supply network and reducing total harmonic distortion. Its compact, booksize-style design ensures easy integration into existing drive systems, making it ideal for multi-axis applications where energy efficiency and dynamic response are critical. This Active Line Module features a built-in line filter and pre-charging circuit, simplifying installation and reducing external components. It supports a rated current of 490A (at 380-480V) and offers a high overload capability of 150% for 60 seconds, ensuring robust performance even under heavy load conditions. The module communicates via DRIVE-CLiQ, providing seamless integration with SINAMICS S120 control units and enabling comprehensive diagnostics and parameterization. Engineered for reliability, the 6SL3310-1TE33-1AA3 operates within a wide temperature range and includes comprehensive protection features such as overcurrent, overvoltage, and overtemperature monitoring. Its regenerative capability not only saves energy but also reduces mechanical wear on braking components, extending system lifespan. Whether used in automotive production lines, cranes, or test stands, this module delivers exceptional performance and efficiency, backed by Siemens' global support and service network. The Siemens 6SL3310-1TE33-1AA3 is a high-performance Active Line Module from the SINAMICS S120 series, designed for regenerative feedback and stable DC link voltage in demanding industrial applications.
Basic Product Information
- Rated power 310kW at 380-480V AC
- Built-in line filter and pre-charging circuit
- DRIVE-CLiQ communication interface
- High overload capability (150% for 60s)
- Compact booksize design for easy integration
- Regenerative feedback for energy savings
Technical Specifications
Version & Model Difference
The 6SL3310-1TE33-1AA3 is part of the SINAMICS S120 Active Line Module family. Compared to earlier versions, this model includes enhanced regenerative feedback efficiency and improved EMC performance with an integrated line filter. It also features a more compact design and updated firmware for better compatibility with newer control units. Unlike the Basic Line Modules (BLM), the Active Line Module provides regulated DC link voltage and lower harmonic distortion, making it suitable for applications with stringent power quality requirements.
Application Scenarios
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is the difference between an Active Line Module and a Basic Line Module?
An Active Line Module (ALM) provides a regulated DC link voltage and supports regenerative feedback, allowing energy to be fed back to the supply network. This reduces energy consumption and harmonic distortion. A Basic Line Module (BLM) is unregulated and does not have regenerative capability, making it less efficient for applications with frequent braking.
Can the 6SL3310-1TE33-1AA3 be used with a 400V supply?
Yes, the module is designed for 380-480V AC supply voltages, so it operates perfectly with a standard 400V industrial power supply. The DC link voltage will be approximately 600V DC under normal conditions.
What is the overload capability of this Active Line Module?
The module can handle 150% of its rated current for 60 seconds and 110% for 120 seconds. This allows for short-term high torque demands without tripping, making it suitable for heavy-duty applications.
Does the module include a built-in line filter?
Yes, the 6SL3310-1TE33-1AA3 comes with an integrated line filter, which helps meet EMC requirements and reduces the need for external filtering components. This simplifies installation and saves panel space.
