Siemens Digital I/O Module 6ES7323-1BH01-0AA0
6ES7323-1BH01-0AA0

Siemens
Siemens Digital I/O Module 6ES7323-1BH01-0AA0
Siemens 6ES7323-1BH01-0AA0 Digital I/O Module. For SIMATIC S7-300. Supplied with full traceability and documentation. Contact us for price, stock and delivery. …
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7323-1BH01-0AA0 |
| Official Product Name | SIMATIC S7-300 SM 323 Digital I/O Module |
| Applicable System | SIMATIC S7-300 |
| Product Type | Digital I/O Module |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Digital outputs | 8, 0.5 A per channel (transistor) |
| Rated load voltage | 24 V DC (20.4 to 28.8 V DC range) |
| Total output current | 2 A (aggregate) |
| Input delay | 1.2 to 4.8 ms |
| Output delay (resistive) | 0 to 1: 100 us; 1 to 0: 500 us |
| Isolation | Optocoupler between channels and backplane bus |
| Power loss (typ.) | 3.5 W |
| Dimensions (W x H x D) | 40 x 125 x 120 mm |
| Weight (approx.) | 220 g |
| Digital inputs | 8 (IEC 61131-2, Type 1) |
Product Description
It is optically isolated and rated for 24 V DC with 0.5 A per output channel, delivering a total current of 2 A for mixed-signal control tasks. This module is widely used to maintain, replace, or retrofit installed S7-300 control cabinets where both input sensing and output switching are required in a single slot. The Siemens 6ES7323-1BH01-0AA0 is a combined digital I/O module in the SIMATIC S7-300 SM 323 family, integrating 8 digital inputs and 8 digital outputs in one 20-pin unit.
Basic Product Information
- Optically isolated channels with 24 V DC rating and 0.5 A per output channel
- Status LEDs for each digital input and output channel for quick commissioning checks
- 20-pin front connector interface consistent with standard S7-300 wiring practice
- Combines 8 digital inputs and 8 digital outputs in one S7-300 signal module
Technical Specifications
Version & Model Difference
The 6ES7323-1BH01-0AA0 is the standard SM 323 8DI/8DO 24 V DC module with a screw-type 20-pin front connector. Newer S7-300 digital modules use the same 20-pin connector and STEP 7 / TIA Portal addressing, but channel counts and current ratings differ by article number; confirm the exact 1BH01 variant before substitution.
Application Scenarios
- Maintenance and retrofit of installed SIMATIC S7-300 control cabinets
- Discrete manufacturing signal acquisition and actuator control
- Mixed small I/O count stations in conveyor and packaging lines
- Spare-part replacement for legacy S7-300 automation systems
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
How many input and output channels does the 6ES7323-1BH01-0AA0 provide?
It provides 8 digital inputs and 8 digital outputs in a single combined module, rated at 24 V DC with 0.5 A per output channel.
Is this module isolated and what front connector is required?
Channels are optically isolated from the backplane bus. It uses a 20-pin front connector such as the screw-type 6ES7392-1BM01-0AA0.
Can it be used in a new S7-300 system design?
Siemens announced product phase-out for this article; it remains available for maintenance, replacement and retrofit of existing S7-300 installations. Contact us for cross-reference and alternative models.
What is the typical power loss of this module?
Typical power loss is 3.5 W. For exact thermal and wiring planning, request the Siemens datasheet via our team.
