Siemens Digital Output Module 6ES7322-1BH01-0AA0
6ES7322-1BH01-0AA0

Siemens
Siemens Digital Output Module 6ES7322-1BH01-0AA0
Siemens 6ES7322-1BH01-0AA0 Digital Output Module. For SIMATIC S7-300 PLC. Supplied with full traceability and documentation. Worldwide shipping from stock. Pri…
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7322-1BH01-0AA0 |
| Official Product Name | SIMATIC S7-300 SM 322 Digital Output Module |
| Applicable System | SIMATIC S7-300 PLC |
| Product Type | Digital Output Module |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Load Voltage L+ | 24 V DC (20.4 to 28.8 V permissible) |
| Output Grouping | 2 groups of 8; 4 A per group, 8 A per module |
| Isolation | Optically isolated |
| Short-circuit Protection | Yes, electronic, about 1 A threshold |
| Inductive Shutdown Limit | Limited to L+ (-53 V) |
| Backplane Bus Current | 5 V DC, max 80 mA |
| Power Loss | Typ. 4.9 W |
| Front Connector | 20-pin |
| Dimensions (W x H x D) | 40 x 125 x 120 mm |
| Weight | Approx. 190 g |
| Number of Outputs | 16 (24 V DC, 0.5 A each) |
Product Description
Siemens 6ES7322-1BH01-0AA0 Digital Output Module. For SIMATIC S7-300 PLC. Supplied with full traceability and documentation. Worldwide shipping from stock.
It uses a 20-pin front connector and green status LEDs, and slots into the S7-300 rack with no fixed slot rule. The module is widely used to switch contactors, solenoids and indicator loads in automation panels. Within the SIMATIC S7-300 I/O family, the Siemens 6ES7322-1BH01-0AA0 delivers 16 electrically isolated 24 V DC digital outputs rated 0.5 A each, grouped as two groups of eight with 4 A per group and 8 A per module.
Basic Product Information
- Optically isolated outputs, grouped 8 per group (4 A/group, 8 A/module)
- Short-circuit protection with electronic response threshold about 1 A
- 20-pin front connector with protected socket behind front door
- Green LEDs for output status; no fixed slot rule in S7-300 rack
- 16 digital outputs, 24 V DC, 0.5 A per channel
Technical Specifications
Version & Model Difference
The 6ES7322-1BH01-0AA0 (16 DO, 24 V DC, 0.5 A) complements the -1BF01 (8 DO, 2 A), -1BL00 (32 DO, 0.5 A) and -1HF01 (8 DO relay) SM 322 variants. Choose channel count and current rating to match the load; all use the same S7-300 rack mounting.
Application Scenarios
- Switching contactors, solenoids and valves in machine control
- Driving 24 V DC indicator lamps and panel signalling
- Material handling and conveyor control outputs
- Retrofit and expansion of SIMATIC S7-300 automation systems
- No. The SM 322 has no slot rule; output addresses are set by the slot position, and it can be hot-swapped when used in ET 200M with active bus modules.
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
How many outputs and what rating does this module have?
It provides 16 digital outputs at 24 V DC, 0.5 A each, arranged in two groups of eight (4 A per group, 8 A per module), with optical isolation and short-circuit protection.
What load voltage range is supported?
The load voltage L+ is rated 24 V DC with a permissible range of 20.4 to 28.8 V DC; backplane current draw is max 80 mA at 5 V DC.
Does it need a fixed slot in the S7-300 rack?
No. The SM 322 has no slot rule; output addresses are set by the slot position, and it can be hot-swapped when used in ET 200M with active bus modules.
What wiring connector is required?
It uses a 20-pin front connector with a protected socket behind the front door and a labeling field; matching Siemens 20-pin connectors and terminal blocks are required.
