Siemens PLC central processing unit 6ES7315-2AH14-0AB0
6ES7315-2AH14-0AB0

Siemens
Siemens PLC central processing unit 6ES7315-2AH14-0AB0
Siemens 6ES7315-2AH14-0AB0 PLC central processing unit. For SIMATIC S7-300. Supplied with full traceability and documentation. Worldwide shipping from stock. P…
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7315-2AH14-0AB0 |
| Official Product Name | SIMATIC S7-300 CPU 315-2 DP |
| Applicable System | SIMATIC S7-300 (STEP 7 V5.5 + SP1 or higher) |
| Product Type | PLC central processing unit (CPU) |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Product family | SIMATIC S7-300 |
| CPU type | CPU 315-2 DP |
| Hardware version | 01 |
| Firmware version | V3.3 |
| Work memory (integrated) | 256 KB (not expandable) |
| Retentive memory | 128 KB |
| Load memory | SIMATIC Micro Memory Card (MMC), max 8 MB |
| Supply voltage | 24 V DC (19.2 - 28.8 V DC) |
| Current consumption (rated) | 850 mA |
| Power loss (typ.) | 4.5 W |
| Bit operation time (typ.) | 0.05 microseconds |
| Word operation time (typ.) | 0.09 microseconds |
| Floating-point operation (typ.) | 0.45 microseconds |
| Communication interfaces | 1 x MPI/DP (X1) + 1 x PROFIBUS DP master/slave (X2) |
| PROFIBUS DP baud rate | 9.6 kbit/s to 12 Mbit/s |
| Counters / timers | 256 / 256 |
| Programming software | STEP 7 V5.5 + SP1 or higher |
| Dimensions (W x H x D) | 40 x 125 x 130 mm |
| Weight | Approx. 0.33 kg |
| Operating temperature | 0 to 60 degrees C |
| Manufacturer | Siemens |
Product Description
Siemens 6ES7315-2AH14-0AB0 PLC central processing unit. For SIMATIC S7-300. Supplied with full traceability and documentation. Worldwide shipping from stock.
It provides 256 KB of integrated work memory and two onboard communication interfaces: an MPI/DP port and a separate PROFIBUS DP master/slave port. The CPU runs on a 24 V DC supply and requires a SIMATIC Micro Memory Card (MMC) for program and data storage, so it operates without a backup battery. It is typically used as the central controller where distributed ET 200 I/O and PROFIBUS field devices must be coordinated. The Siemens 6ES7315-2AH14-0AB0 is the SIMATIC S7-300 CPU 315-2 DP, a mid-range standard controller for modular automation systems.
Basic Product Information
- Two integrated interfaces: MPI/DP (X1) and a dedicated PROFIBUS DP master/slave port (X2) up to 12 Mbit/s
- Fast execution with 0.05 microsecond bit operations and 0.45 microsecond floating-point operations
- Battery-free operation, with program and data held on a SIMATIC Micro Memory Card (MMC, up to 8 MB)
- Supports distributed I/O over PROFIBUS DP and provides 256 integrated counters and 256 timers
- 256 KB integrated work memory (non-expandable) with a 128 KB retentive data area
Technical Specifications
Version & Model Difference
The 6ES7315-2AH14-0AB0 is the AH14 hardware/functional state of the CPU 315-2 DP and replaces the earlier 6ES7315-2AG10-0AB0 and 6ES7315-2AH10-0AB0 variants. This version provides 256 KB of work memory and uses a 24 V DC supply rather than the 120/230 V AC supply found on older S7-300 stock. When cross-referencing, confirm the work-memory size (some 315-2 DP variants offer only 128 KB) and the supply type before substituting.
Application Scenarios
- Medium to large machine and process control in manufacturing
- Distributed automation with ET 200 remote I/O over PROFIBUS DP
- Power generation, chemical, pharmaceutical, water treatment and infrastructure projects
- Maintenance, modernisation and expansion of existing S7-300 installations
- Yes. Program and data are stored on a SIMATIC Micro Memory Card (MMC, up to 8 MB). The CPU runs battery-free and retains data through the MMC.
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is the difference between the 6ES7315-2AH14-0AB0 and earlier 315-2 DP versions?
The AH14 version has 256 KB of integrated work memory and a 24 V DC supply, replacing the older 6ES7315-2AG10-0AB0 and 6ES7315-2AH10-0AB0 parts which had 128 KB and could use an AC supply.
Does the CPU need a memory card?
Yes. Program and data are stored on a SIMATIC Micro Memory Card (MMC, up to 8 MB). The CPU runs battery-free and retains data through the MMC.
How many PROFIBUS DP slaves can it handle?
It has two interfaces: MPI/DP (X1) and a dedicated DP port (X2). As a DP master it can address up to 32 slaves on the second port, and it can also operate as a DP slave.
Which software is required to configure it?
Configuration and programming use STEP 7 V5.5 + SP1 or higher (or STEP 7 V5.2 + SP1 with HSP 218).
