Siemens PLC CPU Module 6ES7216-2BD23-0XB0
6ES7216-2BD23-0XB0

Siemens
Siemens PLC CPU Module 6ES7216-2BD23-0XB0
Siemens 6ES7216-2BD23-0XB0 PLC CPU Module. For SIMATIC S7-200. Supplied with full traceability and documentation. Contact us for price, stock and delivery. Pri…
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7216-2BD23-0XB0 |
| Official Product Name | SIMATIC S7-200 CPU 216-2, DC/DC/DC |
| Applicable System | SIMATIC S7-200 |
| Product Type | PLC CPU Module |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Digital Inputs | 24 x 24 V DC, sink/source |
| Digital Outputs | 16 x 24 V DC transistor (source), 0.5 A per point |
| Program / Data Memory | 24 KB / 10 KB |
| Communication Ports | 2 x RS-485 (PPI/MPI, Modbus RTU, USS), 9.6-115.2 kbps |
| Real-Time Clock | Battery-backed, ±1 min/month @ 25 C |
| High-Speed I/O | 6 counters @ 30 kHz, 2 PWM @ 20 kHz |
| Operating Temperature | 0 C to +55 C |
| Dimensions (W x H x D) | 196 x 80 x 62 mm |
| Weight | 0.55 kg |
| Certifications | CE, UL 508, CSA, FM Class 1 Div 2, RoHS |
| Supply Voltage | 24 V DC (20.4-28.8 V) |
Product Description
It integrates a 24 V DC supply with 24 digital inputs and 16 transistor (source) digital outputs, plus two RS-485 ports for PPI/MPI and freely configurable protocols. The module carries 24 KB of program memory and 10 KB of data memory, a battery-backed real-time clock, and on-board PID auto-tuning across 8 loops. With a 0-55 C operating range and CE/UL/CSA/FM approvals, it suits packaging, pump, conveyor and small SCADA applications. The Siemens 6ES7216-2BD23-0XB0 is the CPU 216-2 controller within the SIMATIC S7-200 micro PLC family, built for compact machine and process control.
Basic Product Information
- Dual RS-485 communication ports: Port 0 (PPI/MPI) and Port 1 (free port for Modbus RTU, USS, user protocol)
- 24 KB program memory and 10 KB data memory with battery-backed real-time clock (±1 min/month)
- On-board PID auto-tune for up to 8 loops, 6 high-speed counters (30 kHz) and 2 PWM outputs (20 kHz)
- Expandable with up to 7 I/O modules (max 256 DI/DO, 32 AI/AO) over the S7-200 bus
- 24 integrated digital inputs (24 V DC, sink/source) and 16 transistor (source) digital outputs rated 0.5 A each
Technical Specifications
Version & Model Difference
The -2BD23-0XB0 denotes the DC/DC/DC configuration (24 V DC inputs, 24 V DC transistor outputs) of the CPU 216-2 with two communication ports. Sibling codes in the S7-200 CPU 216 range include the AC/DC/relay (-2AD23-0XB0) revision; all share the 24 DI/16 DO count and 24 KB program memory but differ in supply/output type. This module belongs to the legacy S7-200 family, for which Siemens now recommends the S7-1200 for new designs.
Application Scenarios
- Medium-speed packaging lines requiring servo triggering and temperature sealing
- Water-booster pump VFD control over Modbus RTU
- Conveyor diverters and barcode tracking stations
- Plastic extruder temperature zones using PID auto-tune
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
- Siemens 5SY6225-8 SENTRON Miniature Circuit Breaker 25A 2P Type D
Frequently Asked Questions
What power supply and output type does the 6ES7216-2BD23-0XB0 use?
It is the DC/DC/DC version: 24 V DC supply (20.4-28.8 V), 24 V DC sink/source inputs, and 16 transistor (source) outputs rated 0.5 A each. It is not a relay-output unit.
How much memory does this CPU have and does it keep the clock?
The CPU provides 24 KB of program memory and 10 KB of data memory, with a battery-backed real-time clock accurate to ±1 minute per month at 25 C.
Which programming software and cable are required?
It is configured with STEP 7-Micro/WIN V4.0 SP9 (or SMART software) using a USB-PPI or PC/PPI cable such as 6ES7 901-3DB30-0XA0.
Is the S7-200 CPU 216-2 still supported for new projects?
The S7-200 family is legacy; Siemens recommends the S7-1200 for new designs, but the 6ES7216-2BD23-0XB0 remains available as a spare/replacement for existing installations.
