Siemens Bus module 6ES7195-7HD10-0XA0
6ES7195-7HD10-0XA0

Siemens
Siemens Bus module 6ES7195-7HD10-0XA0
Siemens 6ES7195-7HD10-0XA0 Bus module. For SIMATIC DP / ET 200M distributed I/O on PROFIBUS DP. Supplied with full traceability and documentation. Get a quote. …
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7195-7HD10-0XA0 |
| Official Product Name | SIMATIC DP Bus Module for ET 200M (for 2x IM153-2 redundant) |
| Applicable System | SIMATIC DP / ET 200M distributed I/O on PROFIBUS DP |
| Product Type | Bus module / bus unit |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | Available on request |
| Product Type | SIMATIC DP bus module for ET 200M |
| Function | Holds 2x IM153-2 (redundant configuration) |
| Insertion / Removal During RUN | Yes (hot-swap) |
| Fieldbus | PROFIBUS DP (via IM153-2 interface modules) |
| Mounting | Rack / DIN-rail mounting in ET 200M |
| Dimensions (W x H x D) | approx. 97 x 92 x 30 mm |
| Net Weight | approx. 0.127 kg |
| Packaging Dimensions (L x W x H) | 10.2 x 10.1 x 6.8 cm |
| Protection Class | IP20 |
| Compliance (listed) | CE, RoHS |
| Product Lifecycle | Spare part; product cancellation announced - confirm availability |
| Article Number | 6ES7195-7HD10-0XA0 |
Product Description
With two interface modules fitted, the station keeps communicating on PROFIBUS DP even if one IM153-2 fails, which is why the part is used where continuous operation matters. The module supports removal and insertion of the IM153-2 modules during RUN, letting technicians replace or inspect an interface module without stopping the plant. It mounts on a standard rail in the ET 200M rack and pairs with S7-300 style I/O modules. Siemens lists this article as a spare part with a product-cancellation notice, so availability should be confirmed for long-term projects. The Siemens 6ES7195-7HD10-0XA0 is a SIMATIC DP bus module for the ET 200M distributed I/O system that carries two IM153-2 interface modules in a redundant configuration.
Basic Product Information
- Accepts two IM153-2 interface modules for a redundant, fault-tolerant station configuration
- Supports removal and insertion of the IM153-2 modules during RUN (hot-swap)
- Keeps PROFIBUS DP communication alive if one interface module fails
- Rack / DIN-rail mounted; pairs with S7-300 style I/O modules
- Compact design that saves control-cabinet space
- Bus module (bus unit) for the SIMATIC ET 200M distributed I/O system on PROFIBUS DP
Technical Specifications
Version & Model Difference
The 6ES7195-7HD10-0XA0 is the 2x IM153-2 redundant bus module of the ET 200M bus-module family. Standard ET 200M bus modules accept a single interface module, whereas this unit is specifically built to carry two IM153-2 modules so a high-availability station can be assembled. It is intended for use with IM153-2 interface modules (for example the 6ES7153-2AR04-0XA0 / 6ES7153-2BA10-0AB0 family) rather than the single-channel IM153-1. Siemens lists this article as a spare part under product cancellation, so for new designs an alternative ET 200M or ET 200SP/ET 200MP platform may be preferable; confirm the exact interface module pairing before ordering.
Application Scenarios
- High-availability distributed I/O stations in automotive, chemical and process plants
- Power generation, water/wastewater and other continuous processes where downtime is costly
- Maintenance spares and expansion of existing ET 200M redundant systems
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is the 6ES7195-7HD10-0XA0?
It is a SIMATIC DP bus module for the ET 200M I/O system that carries two IM153-2 interface modules for redundant operation.
Can the IM153-2 modules be changed without stopping the plant?
Yes - the module supports removal and insertion of the IM153-2 modules during RUN, so an interface module can be replaced without halting operation.
Which interface modules does it hold?
It is designed for two IM153-2 modules (e.g. 6ES7153-2AR04-0XA0 or 6ES7153-2BA10-0AB0); the single-channel IM153-1 is not used in this redundant module.
Is this article still available?
Siemens lists it as a spare part with a product-cancellation notice; stock is limited, so please confirm current availability when you request a quote.
