Siemens Redundant Interface Module Bundle 6ES7153-2AR04-0XA0
6ES7153-2AR04-0XA0

Siemens
Siemens Redundant Interface Module Bundle 6ES7153-2AR04-0XA0
Siemens 6ES7153-2AR04-0XA0 Redundant Interface Module Bundle. For SIMATIC ET 200M distributed I/O. Supplied with full traceability and documentation. Price &am…
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7153-2AR04-0XA0 |
| Official Product Name | SIMATIC DP, ET 200M Red. Bundle (2x IM 153-2 HF + bus module) |
| Applicable System | SIMATIC ET 200M distributed I/O (PROFIBUS DP, redundant) |
| Product Type | Redundant Interface Module Bundle |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Communication protocol | PROFIBUS DP (V1), redundant |
| Supply voltage range | 20.4 to 28.8 V DC |
| Potential separation | Yes |
| Degree of protection | IP20 |
| Dimensions (W x H x D) | 40 x 125 x 120 mm |
| Modules per DP slave interface, max | 12 (per IM 153-2 HF) |
| Address area inputs / outputs | 244 byte / 244 byte |
| Ambient operating temperature | 0 to +60 °C |
| Mounting | 35 mm DIN rail / ET 200M rack with active bus module |
| Compatibility | S7-400H / S7-400FH, S7-300 SM/FM/CP/F modules |
| Bundle contents | 2x IM 153-2 HF (6ES7153-2BA10-0XB0) + 1x bus module in/in (6ES7195-7HD10-0XA0) |
Product Description
Siemens 6ES7153-2AR04-0XA0 Redundant Interface Module Bundle. For SIMATIC ET 200M distributed I/O. Supplied with full traceability and documentation.
Bundle, a ready-to-install redundant interface package for high-availability distributed I/O. It consists of two IM 153-2 High Feature interface modules (6ES7153-2BA10-0XB0) plus one in/in bus module (6ES7195-7HD10-0XA0). The pair backs up each other on a PROFIBUS DP link so an ET 200M station stays online even if one communication path fails, making it the backbone of fault-tolerant S7-400H automation architectures. The Siemens 6ES7153-2AR04-0XA0 is the SIMATIC DP ET 200M Red.
Basic Product Information
- Bumpless redundancy switchover between primary and backup interface modules with zero process interruption
- PROFIBUS DP communication up to 12 Mbit/s with hot-swappable modules during live operation
- Supports up to 12 S7-300 I/O modules per station with isochronous mode, time stamping and HART variables
- Compatible with SIMATIC S7-400H / S7-400FH controllers for high-availability and fault-tolerant systems
- Factory redundant bundle: 2x IM 153-2 HF (6ES7153-2BA10-0XB0) plus 1x bus module in/in (6ES7195-7HD10-0XA0)
Technical Specifications
Version & Model Difference
The 6ES7153-2AR04-0XA0 is not a single module but a redundant bundle built around two IM 153-2 HF interface modules (6ES7153-2BA10-0XB0). It replaces the older practice of ordering IM modules and bus modules separately for S7-400H ET 200M stations. The contained IM 153-2 HF is the active successor generation of the 2BA02 variant, sharing the same footprint and feature set (redundancy, time stamping, HART, isochronous mode).
Application Scenarios
- High-availability process automation where ET 200M station downtime is unacceptable
- S7-400H redundant controller systems in chemical, pharmaceutical and power plants
- Fault-tolerant distributed I/O for water treatment and automotive assembly lines
- Retrofit of existing ET 200M stations to redundant PROFIBUS DP architecture
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is actually included in the 6ES7153-2AR04-0XA0 bundle?
It is a SIMATIC DP ET 200M Red. Bundle containing two IM 153-2 High Feature interface modules (6ES7153-2BA10-0XB0) and one bus module in/in (6ES7195-7HD10-0XA0), pre-matched for redundant operation.
Does the bundle support hot-swapping during operation?
Yes. The IM 153-2 HF modules are hot-swappable with active bus modules, so a faulty interface can be replaced during live operation without shutting down the ET 200M station.
Which controllers is this redundant bundle designed for?
It is intended for SIMATIC S7-400H and S7-400FH high-availability controllers, providing bumpless failover between the two PROFIBUS DP communication paths.
How many I/O modules can one redundant station host?
Each IM 153-2 HF supports up to 12 S7-300 modules per DP slave interface, with 244 byte input and 244 byte output address space and full SM/FM/CP/F compatibility.
