Siemens PROFINET IO Interface Module 6ES7151-3AA23-0AB0
6ES7151-3AA23-0AB0

Siemens
Siemens PROFINET IO Interface Module 6ES7151-3AA23-0AB0
Siemens 6ES7151-3AA23-0AB0 PROFINET IO Interface Module. For SIMATIC ET 200S. Supplied with full traceability and documentation. Worldwide shipping from stock. …
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7151-3AA23-0AB0 |
| Official Product Name | SIMATIC ET 200S IM 151-3 PN ST Interface Module |
| Applicable System | SIMATIC ET 200S |
| Product Type | PROFINET IO Interface Module |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Transmission Rate | 100 Mbit/s full-duplex |
| PROFINET Ports | 2 x RJ45 (integrated switch) |
| Max I/O Modules | 63 |
| Max Station Width | 2 m |
| Address Area | 256 byte inputs / 256 byte outputs |
| Real-Time | RT and IRT |
| Supply Voltage | 24 V DC |
| Current Consumption | approx. 200 mA |
| Power Loss | typ. 3.3 W |
| Protection | IP20 |
| Dimensions | 60 x 119.5 x 75 mm |
| Weight | approx. 150 g |
| MMC | Required (64 KB for device name) |
| Network | PROFINET IO |
Product Description
Siemens 6ES7151-3AA23-0AB0 PROFINET IO Interface Module. For SIMATIC ET 200S. Supplied with full traceability and documentation. Worldwide shipping from stock.
It connects peripheral, motor-starter and function modules to a PROFINET IO controller over a 100 Mbit/s full-duplex link with an integrated 2-port switch. The module supports RT and IRT, up to 63 modules across a 2 m station width, and diagnostics via LED indicators. An MMC is required to store the device name. 6ES7151-3AA23-0AB0 is the Siemens SIMATIC ET 200S IM 151-3 PN Standard PROFINET interface module that serves as the communication head of an ET 200S distributed I/O station.
Basic Product Information
- Supports up to 63 I/O modules across a 2 m station width
- RT and IRT communication with MRP, Shared Device and SNMP support
- Module diagnostics via SF, BF, ON and LINK LEDs
- PROFINET IO interface at 100 Mbit/s full-duplex with integrated 2-port switch
Technical Specifications
Version & Model Difference
IM 151-3 PN (6ES7151-3AA23-0AB0) is the Standard (ST) PROFINET version of the ET 200S interface. For PROFIBUS DP instead of PROFINET, use the IM 151-1 (6ES7151-1AA05-0AB0). Confirm the bus type before replacement.
Application Scenarios
- Distributed I/O close to field devices in manufacturing automation
- Automotive assembly lines and machine tool applications
- Process industries requiring isochronous real-time I/O
- Yes, a SIMATIC Micro Memory Card is required; 64 KB is sufficient to store the PROFINET device name, while 4 MB or more is needed for firmware updates.
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
How many modules can the IM 151-3 PN support?
The 6ES7151-3AA23-0AB0 supports up to 63 power, electronic and motor-starter modules within an ET 200S station width of up to 2 m.
Does the IM 151-3 PN need an MMC?
Yes, a SIMATIC Micro Memory Card is required; 64 KB is sufficient to store the PROFINET device name, while 4 MB or more is needed for firmware updates.
What transmission speed and topology does it support?
It runs PROFINET IO at 100 Mbit/s full-duplex with two integrated RJ45 ports forming a line, star or ring topology without external switches.
Which real-time communication modes are available?
The module supports RT and IRT (isochronous real-time) with MRP media redundancy, Shared Device and SNMP diagnostics.
