Siemens Digital Output Module 6ES7132-4BF00-0AA0
Siemens
Siemens Digital Output Module 6ES7132-4BF00-0AA0
Home > Siemens > SIMATIC ET 200S > 6ES7132-4BF00-0AA0 Need Siemens 6ES7132-4BF00-0AA0? Digital Output Module for SIMATIC ET 200S. Supplied with full t…
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 6ES7132-4BF00-0AA0 |
| Official Product Name | SIMATIC ET 200S 8DO DC24V/0.5A Electronic Module |
| Applicable System | SIMATIC ET 200S |
| Product Type | Digital Output Module |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Rated output current | 0.5 A per channel (7 mA to 0.6 A range) |
| Total output current (per module) | 4 A |
| Short-circuit protection | Yes, typical response threshold 1.5 A |
| Output delay (resistive) | 0 to 1: 300 us; 1 to 0: 600 us |
| Switching frequency | Resistive 100 Hz, inductive 2 Hz, lamp 10 Hz |
| Load resistance range | 48 ohm to 3.4 kohm |
| Cable length | Shielded 1000 m max, unshielded 600 m max |
| Isochronous operation | Yes (jitter < 100 us) |
| Power loss (typ.) | 1.5 W |
| Dimensions (W x H x D) | 15 x 81 x 52 mm |
| Weight (approx.) | 40 g |
| Number of digital outputs | 8, 24 V DC |
Product Description
It is housed in a slim 15 mm-wide body with integrated short-circuit protection and electrical isolation between the output group and the backplane bus. The module supports isochronous operation and shows a green status LED per channel for commissioning and maintenance. The Siemens 6ES7132-4BF00-0AA0 is an electronic output module for the SIMATIC ET 200S distributed I/O system, delivering 8 digital outputs at 24 V DC with 0.5 A per channel and a 4 A aggregate module current.
Basic Product Information
- Integrated short-circuit protection with typical 1.5 A response threshold
- Isochronous mode support with low jitter for synchronized switching
- Per-channel green status LED and isolation from the backplane bus
- 8 digital outputs at 24 V DC, 0.5 A per channel, 4 A total module current
Technical Specifications
Version & Model Difference
The 6ES7132-4BF00-0AA0 is the standard 8DO DC24V/0.5A electronic module of the 15 mm ET 200S family. It requires a compatible ET 200S terminal module (e.g. TM-E15C26 or TM-E15S26). Source/sink and high-feature output modules carry different article numbers and are not interchangeable without rewiring review.
Application Scenarios
- Reliable load switching in distributed SIMATIC ET 200S I/O stations
- Actuator, solenoid and lamp control in control cabinets
- Expansion of output points on existing ET 200S installations
- Synchronized switching tasks requiring isochronous operation
- Siemens 6ES7214-1BH50-0XB0 SIMATIC S7-1200 G2 CPU 1214C AC/DC/RLY
- Siemens 6ES7231-4HF50-0XB0 SIMATIC S7-1200 G2 SM 1231 Analog Input Module
- Siemens 6ES7231-5PD50-0XB0 SIMATIC S7-1200 G2 SM 1231 RTD Module
- Siemens 6ES7216-2BD23-0XB0 SIMATIC S7-200 CPU 216-2 DC/DC/DC
- Siemens 6ES7223-1BH22-0XA0 SIMATIC S7-200 EM 223 Digital I/O Module 8DI/8DO
- Siemens 6ES7223-5PH50-0XB0 SIMATIC S7-1200 G2 SM 1223 Digital I/O 8DI/8RLY
Frequently Asked Questions
What is the output current rating of the 6ES7132-4BF00-0AA0?
It provides 8 outputs at 24 V DC, 0.5 A per channel, with a 4 A total module current and built-in short-circuit protection.
Which terminal module does it need?
It mounts on a 15 mm ET 200S terminal module such as the TM-E15C26-A1 or TM-E15S26-A1 (screw or spring type).
Does it support isochronous operation?
Yes, the module supports isochronous mode with jitter below 100 us, suitable for synchronized switching applications.
Can outputs be paralleled for higher current?
Two outputs may be paralleled for redundant control of a single load, but not for uprating total current. Contact us for cross-reference and alternative models if more current is required.
