Siemens Miniature Circuit Breaker 5SY6225-8 / 5SY6 D 25A/2P
Siemens
Siemens Miniature Circuit Breaker 5SY6225-8 / 5SY6 D 25A/2P
Home > Products > Circuit Breakers > Siemens > 5SY6225-8 Need Siemens 5SY6225-8 / 5SY6 D 25A/2P? Miniature Circuit Breaker for Low voltage distribu…
Specifications
| Brand | Siemens |
|---|---|
| Model Number | 5SY6225-8 / 5SY6 D 25A/2P |
| Official Product Name | Circuit Breaker (EFH) |
| Applicable System | Low voltage distribution systems |
| Product Type | Miniature Circuit Breaker (MCB) |
| Equivalent Standard | 5SY6225-8, 5SY6 D 25A/2P |
| Product Status | Active |
| Number of Poles | 2P |
| Tripping Curve | D |
| Rated Breaking Capacity | 6 kA (EN 60898) |
| Rated Voltage | 400 V AC (working); 440 V Ui; 72 V DC |
| Frequency | 50/60 Hz |
| Mounting Type | DIN rail |
| Standards | IEC/EN 60898-1, IEC/EN 60947-2 |
| Terminal Capacity | 1-25 mm2 |
| Degree of Protection | IP20 (with connected conductors) |
| Operating Temperature | -25 degC to +55 degC |
| Storage Temperature | -40 degC to +70 degC |
| Dimensions | 36 x 90 x 76 |
| Weight | 280 g |
| Rated Current (In) | 25 A |
Product Description
12.00 USD （参考价 / est. market price）
Basic Product Information
- 2-pole configuration for single-phase or two-wire systems
- D tripping curve for high inrush current applications (e.g., motors, transformers)
- Rated current of 25A
- Compact design for DIN rail mounting
- High reliability and long service life
- 6kA breaking capacity per IEC 60898-1
Technical Specifications
Version & Model Difference
The model 5SY6225-8 is the standard version with a D curve. There are no significant regional variations for this model. The 5SY6 series is the current generation, replacing older 5SY4 series. The '8' suffix indicates the breaking capacity of 6kA.
Application Scenarios
- Industrial motor protection
- Transformer primary protection
- Commercial building distribution boards
- Pump and compressor control panels
