TM3AM6-module

Product Description

This module provides 4 analog input channels, each configurable for voltage (0-10 V DC) or current (0-20 mA) signals, with a 16-bit resolution ensuring precise data acquisition. The TM3AM6 is engineered for industrial environments, offering robust electrical isolation and compliance with IEC 61131-2 standards, making it suitable for a wide range of process control and monitoring applications. This module features a compact design that saves panel space while delivering reliable performance. It supports non-isolated inputs with a common reference, and each channel can be individually configured via the controller's programming software (SoMachine or EcoStruxure Machine Expert). The TM3AM6 is hot-swappable in some configurations, but it is typically installed on a TM3 bus, allowing easy expansion of I/O capacity. The module operates within a temperature range of 0°C to 60°C and has a protection rating of IP20, suitable for cabinet mounting. With its high accuracy and fast conversion time, the TM3AM6 is ideal for applications such as monitoring temperature sensors, pressure transducers, and other analog signals in automation systems. It is a genuine Schneider Electric product, ensuring compatibility and long-term reliability. The module is available as a new original unit with a standard warranty, and it is part of the Modicon TM3 series that is widely used in packaging, material handling, and machine building industries. The Schneider TM3AM6 is a high-performance analog input module from the Modicon TM3 family, designed for use with Modicon M241, M251, and M258 logic controllers.

Basic Product Information

• Configurable for voltage (0-10 V DC) or current (0-20 mA) signals
• High accuracy: ±0.5% of full scale at 25°C
• Fast conversion time: 1 ms per channel
• Non-isolated inputs with common reference
• Compact design for space-saving installation
• Compatible with SoMachine and EcoStruxure Machine Expert software
• IP20 protection rating for cabinet mounting
• 4 analog input channels with 16-bit resolution

Technical Specifications

Version & Model Difference

The TM3AM6 is part of the Modicon TM3 I/O family. There are no major version differences for this model, but it is important to note that the TM3AM6 is a standard analog input module. For applications requiring isolated inputs, Schneider offers the TM3AI4 (isolated) or TM3AI8 (8-channel) modules. The TM3AM6 is designed for non-isolated applications, which is a key consideration when selecting the appropriate module for your system. Always check the firmware version of your controller to ensure compatibility with the TM3AM6.
