Phoenix Contact Sensor 1404408
Phoenix Contact
Phoenix Contact Sensor 1404408
Home > Phoenix Contact > Sensor/Actuator Cables > 1404408 Need Phoenix Contact 1404408? Sensor for M12 A-coded sensor/actuator connectivity. Supplied …
Specifications
| Brand | Phoenix Contact |
|---|---|
| Model Number | 1404408 |
| Official Product Name | SAC-4P-5,0-PVC/M12FS Sensor/Actuator Cable |
| Applicable System | M12 A-coded sensor/actuator connectivity (IEC 61076-2-101) |
| Product Type | Sensor/Actuator Cable (single-ended cordset) |
| Equivalent Standard | IEC 61076-2-101; UL AWM Style 2464 / 1729 |
| Product Status | In Stock |
| Number of positions | 4 |
| Coding | A |
| Connection 1 | Free cable end |
| Connection 2 | Socket straight M12 |
| Cable length | 5 m |
| Cable type | PVC, black RAL 9005 |
| Conductor cross section | 4 x 0.34 mm2 (AWG 22) |
| External cable diameter | 4.70 mm +/- 0.15 mm |
| Nominal voltage | 250 V AC / 250 V DC |
| Nominal current | 4 A |
| Degree of protection | IP65 / IP67 / IP68 |
| Ambient temperature (operation) | -25 C ... 80 C fixed, -10 C ... 80 C flexible |
| Insertion/withdrawal cycles | >= 100 |
| Standard | IEC 61076-2-101 |
| Weight | approx. 160 g |
| Product type | Sensor/actuator cable |
Product Description
One end carries a straight, A-coded 4-pin M12 female connector and the other terminates in bare flying leads, making it a single-ended connection cable for proximity sensors, valve plugs and actuator wiring. The PVC jacket and four 0.34 mm2 (22 AWG) conductors are rated 250 V AC / 250 V DC and 4 A, with IP65, IP67 and IP68 protection when mated. It is a standard-length connectivity item used throughout machine building, conveyor and packaging installations. The Phoenix Contact 1404408 is a 5-metre sensor/actuator cordset from the SAC-4P product family.
Basic Product Information
- 5 m PVC cable in black RAL 9005 with four 0.34 mm2 (22 AWG) conductors
- Rated 250 V AC / 250 V DC and 4 A nominal current
- IP65, IP67 and IP68 degree of protection when mated
- TPU grip body with nickel-plated zinc die-cast coupling nut and gold/nickel-plated CuSn contacts
- 100 % electrically tested plug-in component, halogen-free style PVC cable to UL AWM 2464
- 4-position, A-coded straight M12 female connector on one end and a free cable end on the other
Technical Specifications
Version & Model Difference
This 5 m version differs from other SAC-4P-5,0-PVC/M12FS lengths (0.3 m to 10 m) only by cable length and, in some references, connector style. The electrical rating, PVC jacket and A-coding are identical across the family. The M12FS suffix denotes an M12 female straight socket; a right-angle variant is available separately.
Application Scenarios
- Proximity and photoelectric sensor wiring on conveyors and indexing units
- Valve plug and actuator connections in packaging machinery
- Machine-building panel-to-field signal and 24 V DC power connections
- Pre-assembled field wiring where a 5 m M12 female to bare-lead cordset is required
- Phoenix Contact UK 5-HESILA 250 Fuse Terminal Block
- Phoenix Contact UK 5-HESILA 24 Fuse Terminal Block
- Phoenix Contact ST 1.5 Feed-Through Terminal Block
- Phoenix Contact 3101197 MTK BU Knife-Disconnect Terminal Block
- Phoenix Contact 2966061 PLC-BSC-24DC/1/SEN Relay Base
- Phoenix Contact 2901535 RAD-DI4-IFS Radioline Digital I/O Extension Module
- Phoenix Contact 2866789 QUINT-PS/1AC/24DC/40 Power Supply
Frequently Asked Questions
What connector type does the Phoenix Contact 1404408 use?
It has a straight, A-coded 4-pin M12 female socket on one end and bare flying leads on the other; the cable is 5 m long.
What is the voltage and current rating of the 1404408?
The cordset is rated 250 V AC / 250 V DC and 4 A nominal current, with an insulation resistance of at least 100 MOhm.
Is the 1404408 protected against water and dust?
Yes. When mated the connector achieves IP65, IP67 and IP68 protection; the free cable end itself is not sealed.
Can this cable be used in drag-chain or moving applications?
It is a standard PVC cable intended mainly for fixed installation; the minimum bending radius is 5 x D fixed and 10 x D when flexible.
