Pepperl+Fuchs Solenoid Driver D1010D
Pepperl+Fuchs
Pepperl+Fuchs Solenoid Driver D1010D
Home > Products > Pepperl+Fuchs > Solenoid Drivers Need Pepperl+Fuchs D1010D? Solenoid Driver for K-System. Supplied with full traceability and docume…
Specifications
| Brand | Pepperl+Fuchs |
|---|---|
| Model Number | D1010D |
| Official Product Name | Solenoid Driver |
| Applicable System | K-System (KFD2-Series) |
| Product Type | Solenoid Driver / Valve Driver |
| Equivalent Standard | IEC 61508 (SIL 2), ATEX, IECEx |
| Product Status | In Stock |
| Output Current | 52 mA (max) |
| Output Voltage | 24V DC (nominal) |
| Intrinsic Safety | Ex ia IIC (Zone 0/1/2) |
| Safety Integrity Level | SIL 2 (IEC 61508) |
| Galvanic Isolation | Yes, input/output |
| LED Indication | Power and fault status |
| Ambient Temperature | -20°C to +60°C |
| Mounting | DIN rail (35mm) |
| Protection Class | IP20 (housing) |
| Dimensions (WxHxD) | 20 x 100 x 115 mm |
| Weight | Approx. 150 g |
| Supply Voltage | 24V DC (20-30V DC) |
Product Description
It provides a controlled output to operate solenoid valves in hazardous areas, ensuring reliable and safe operation. This device is part of the Pepperl+Fuchs K-System, which is known for its modularity and ease of use in process automation. With a supply voltage of 24V DC and an output current of up to 52 mA, the D1010D is capable of driving a wide range of solenoid valves. It features a compact design that saves space on DIN rails, and its pluggable terminals simplify wiring and maintenance. The device is certified for use in Zone 0, Zone 1, and Zone 2 hazardous areas, making it suitable for a variety of industrial applications. The D1010D is designed to meet the highest safety standards, including SIL 2 (Safety Integrity Level) according to IEC 61508. It offers galvanic isolation between the input and output circuits, providing protection against voltage spikes and ensuring signal integrity. The device is also equipped with LED indicators for status monitoring, allowing for quick diagnostics and troubleshooting. The Pepperl+Fuchs D1010D is a high-performance solenoid driver designed for use in intrinsically safe applications.
Basic Product Information
- Supply voltage 24V DC (20-30V DC range)
- Output current up to 52 mA
- Galvanic isolation between input and output
- LED status indication for power and fault
- Compact housing for DIN rail mounting
- SIL 2 certified for safety applications
- Pluggable terminals for easy wiring
- Intrinsically safe output for solenoid valves
Technical Specifications
Version & Model Difference
The D1010D is part of the Pepperl+Fuchs K-System series. It is an updated version of the earlier D1010 series, featuring improved isolation and a more compact design. The D1010D is functionally equivalent to the KFD2-SD-Ex1.12450 model but with a different housing style. It is designed to be compatible with existing K-System infrastructure.
