Parker Screw-in cartridge pressure reducing valve PRH102S30
Parker Hannifin
Parker Screw-in cartridge pressure reducing valve PRH102S30
['Home', 'Hydraulics', 'Parker Valves', 'Pressure Reducing', 'PRH102S30'] Need Parker PRH102S30? Screw-in car…
Specifications
| Brand | Parker Hannifin |
|---|---|
| Model Number | PRH102S30 |
| Official Product Name | Pilot Operated Pressure Reducing Valve |
| Applicable System | Hydraulics / Industrial and mobile |
| Product Type | Screw-in cartridge pressure reducing valve |
| Equivalent Standard | ISO 4406 18/16/13 |
| Product Status | Active |
| Pressure control range | 41.4-210 bar (600-3000 psi) |
| Standard setting | 103.5 bar (1500 psi) |
| Max inlet pressure | 380 bar (5500 psi) |
| Max operating pressure | 350 bar (5000 psi) |
| Max drain flow | 0.94 L/min (0.25 GPM) |
| Cavity | C10-3 |
| Adjustment | Screw adjust |
| Seal material | D-Ring (standard) |
| Weight | 0.23 kg (0.5 lb) |
| Rated flow | 56.3 L/min (15 GPM) |
Product Description
Basic Product Information
- Flow up to 56.3 L/min (15 GPM)
- Pressure range 41.4-210 bar (600-3000 psi)
- Screw adjust, cavity C10-3
- All-steel hardened construction, D-Ring seals
- Pilot-operated pressure reducing + relieving
Technical Specifications
Version & Model Difference
['PRH102S30 (range 600-3000 psi) vs PRH102S10/S30 variants: differ by pressure spring code.', 'PRH102 (pilot operated) vs direct-acting reducers: lower hysteresis and better regulation under flow change.']
Application Scenarios
- Clamp and fixture pressure control
- Dual-pressure and pilot control circuits
- Downstream sub-circuit regulation
