Microlab Coaxial load TA2MN
Home / RF Passives / Terminations / Microlab TA-2MN Need Microlab TA2MN? Coaxial load for Wireless and general RF test and distribution. Supplied with full tra…
Specifications
| Brand | Microlab (FXR) |
|---|---|
| Model Number | TA-2MN |
| Official Product Name | 2 W N-Type male resistive termination, DC-6 GHz |
| Applicable System | Wireless and general RF test and distribution |
| Product Type | Coaxial load / termination |
| Equivalent Standard | RoHS; 50 ohm nominal |
| Product Status | Active |
| Lifecycle note | Commercialized |
| Power rating | 2 W average (2 kW peak) |
| Impedance | 50 ohm nominal |
| Connector | N-type male |
| VSWR | 1.15:1 at 2 GHz (typ.) |
| Length | 1.4 in (36 mm) |
| Weight | 1.7 oz (47 g) |
| Frequency range | DC - 6 GHz |
Product Description
Basic Product Information
- 2 W average power rating
- 50 ohm impedance with low VSWR
- N-type male connector, lightweight 47 g
- DC to 6 GHz wideband operation
Technical Specifications
Version & Model Difference
- ['TA-2MN is the N-type male 2 W DC-6 GHz termination', 'TA-2MHE uses 4.3-10; TA-2MD uses 7/16 DIN connectors', 'Product change (2024) extended frequency to DC-6 GHz and added heat sink']
Application Scenarios
- RF test and measurement
- Wireless system termination
- Spare port loading in DAS and combiners
