PTQ-PDPMV1
Prosoft PROFIBUS DP V1 Master PTQ-PDPMV1
Other Brands
Prosoft PROFIBUS DP V1 Master PTQ-PDPMV1
['Home', 'ProSoft', 'PTQ-PDPMV1 PROFIBUS DP Master Module'] Need Prosoft PTQ-PDPMV1? PROFIBUS DP V1 Master communication module f…
Specifications
| Brand | ProSoft |
|---|---|
| Model Number | PTQ-PDPMV1 |
| Official Product Name | Quantum PROFIBUS DP V1 Master Network Interface Module |
| Applicable System | Schneider Electric Quantum PLC systems |
| Product Type | PROFIBUS DP V1 Master communication module |
| Equivalent Standard | IEC 61158, PROFIBUS Trade Organisation certified |
| Product Status | Available (legacy ProTalk series) |
| Max Slaves | 125 |
| Baud Rate | 9.6 kbps to 12 Mbps (auto-detect) |
| Cyclic Data | Up to 1536 bytes input / output |
| Backplane Current | 800 mA at 5 VDC |
| Operating Temperature | 0 to 60 deg C |
| PROFIBUS Port | DB-9 female, optically isolated RS-485 |
| Weight | Approx. 0.50 kg |
| Protocol | PROFIBUS DP V0 / V1 (IEC 61158) |
Product Description
It enables high-speed cyclic and acyclic data exchange with up to 125 PROFIBUS DP slaves, with Hot Standby redundancy and configuration via ProSoft Configuration Builder. The ProSoft PTQ-PDPMV1 is a PROFIBUS DP V1 Master network interface module for Schneider Electric Quantum PLC platforms.
Basic Product Information
- Up to 125 slave devices, baud up to 12 Mbps
- Hot Standby redundancy with < 300 ms switchover
- Configured via ProSoft Configuration Builder (PCB)
- PROFIBUS DP V0 / V1 Master for Quantum backplane
Technical Specifications
Version & Model Difference
- The PTQ-PDPMV1 is the single-port PROFIBUS DP V1 Master; related ProTalk modules cover other networks (e.g. Modbus, EtherNet/IP) and DPV0-only variants.
Application Scenarios
- Connecting Quantum PLCs to PROFIBUS DP field networks
- Wastewater, automotive, and food and beverage automation
- Redundant (Hot Standby) process control architectures
Frequently Asked Questions
What does the PTQ-PDPMV1 do?
It is a PROFIBUS DP V1 Master module for Schneider Electric Quantum PLCs, exchanging cyclic and acyclic data with up to 125 PROFIBUS DP slaves.
What are the communication limits?
It supports baud rates up to 12 Mbps, up to 125 slaves, and up to 1536 bytes of cyclic input / output data.
Does it support redundancy?
Yes, it supports Hot Standby configurations with a nominal switchover well under 300 ms for continuous operation.
How is it configured?
Configuration and diagnostics are performed with ProSoft Configuration Builder (PCB) software via Ethernet or serial connection.
Need PTQ-PDPMV1?
Get a Quote in Minutes.
12-month warranty · No MOQ · Worldwide shipping with tracking
Request a Quote
Get the latest price, stock status and bulk order discount for PTQ-PDPMV1. Our team replies within 30 minutes (working hours).
