ANDERSON Blade type PLUG-IN,SB3506320G1 350A-600V,ANDERSON
PLUG-INSB3506320G1-350A-600VANDERSON
Other Brands
ANDERSON Blade type PLUG-IN,SB3506320G1 350A-600V,ANDERSON
Home > ANDERSON > Power Connectors > SB350 6320G1 Need ANDERSON PLUG-IN,SB3506320G1 350A-600V,ANDERSON? Contact us for price, stock and delivery. Full…
Contact us for current availability and best price of PLUG-INSB3506320G1-350A-600VANDERSON.
Specifications
| Brand | ANDERSON POWER PRODUCTS |
|---|---|
| Model Number | 6320G1 (SB350) |
| Official Product Name | PLUG-IN, SB3506320G1 350A-600V |
| Applicable System | SB 350 series high-current power connections (battery, EV, UPS, industrial) |
| Product Type | Blade type power connector - 2 position non-gendered plug kit |
| Equivalent Standard | Anderson SB 350 series; RoHS3 compliant, UL 94V-0 housing |
| Product Status | In Stock |
| Manufacturer part number | 6320G1 |
| Connector type | Non-gendered (hermaphroditic) blade power connector |
| Number of positions / poles | 2 |
| Current rating | 350 A |
| Voltage rating | 600 V |
| Wire gauge | 2/0 AWG (approx. 67.4 mm2) |
| Termination | Crimp |
| Mounting type | Free hanging / in-line |
| Contact material | Copper alloy, silver plated |
| Housing material | Polycarbonate (PC), grey |
| Fastening type | Spring retention |
| Operating temperature | -20 C to 105 C |
| Flammability rating | UL 94V-0 |
| RoHS / REACH | RoHS3 compliant / REACH unaffected |
| Kit contents | 1 x grey SB350 housing plus 2 x 2/0 AWG contacts |
| Manufacturer series | SB 350 |
Product Description
It is a two-pole, non-gendered (hermaphroditic) in-line connector: any SB 350 housing mates with any other SB 350 housing of the same colour, so no male or female versions are needed. The kit includes the grey polycarbonate housing and two silver-plated copper contacts for 2/0 AWG cable, terminated by crimping. With spring retention, colour-coded keying and UL 94V-0 material, it is widely used for high-current battery, electric vehicle, UPS and industrial power interconnections. The Anderson Power Products 6320G1 is a complete SB 350 series plug kit rated 350 A at 600 V.
Basic Product Information
- High current rating of 350 A at up to 600 V for heavy-duty power links
- Silver-plated copper alloy contacts for low-resistance, reliable connections
- Colour-coded housings help prevent cross-connection mistakes
- Spring retention fastening for a secure, vibration-resistant in-line joint
- UL 94V-0 polycarbonate housing with a wide -20 C to 105 C operating range
- Non-gendered (hermaphroditic) design - any SB 350 housing mates with any other of the same colour
Technical Specifications
Version & Model Difference
The 6320G1 is the grey SB 350 kit supplied with 2/0 AWG contacts (housing 906-BK plus two 907-BK terminals). Other SB 350 kits share the same housing but differ in colour and contact size, for example versions supplied for 1/0 AWG or 3/0 AWG cable. SB 350 housings only mate with the same colour, so always match colour and cable size to the mating half of the installation.
Application Scenarios
- Battery packs and battery chargers for industrial equipment
- Electric vehicle and electric pallet truck power connections
- UPS systems, telecommunications and power electronics DC links
- Wheelchair, mobility and other high-current mobile power connections
- ANDERSON SB3506320G1 350A-600V DC Contactor (SB3506320G1)
Frequently Asked Questions
Is the 6320G1 a male or female connector?
Neither. It is a non-gendered (hermaphroditic) SB 350 connector, so it mates with any other SB 350 housing of the same colour - just turn one housing 180 degrees to connect.
What current and voltage does it handle?
The SB 350 series 6320G1 is rated 350 A at up to 600 V, using 2/0 AWG cable with crimped silver-plated contacts.
What is included in the kit?
One grey SB 350 polycarbonate housing plus two silver-plated copper contacts for 2/0 AWG cable; the contacts are crimped onto the cable.
How should I ensure a correct mating connection?
SB 350 housings are colour coded and only mate with the same colour, which prevents accidental cross-connection between different circuits.
