PGW-7200-804-P1-2PDS-BA670A1

Product Description

This model, also identified by the field label 2PDS-BA670A1, is part of the PGW series known for its accuracy and reliability. It converts process pressure into a standard 4-20 mA analog output signal, making it compatible with most control systems, PLCs, and SCADA systems. The transmitter is built with robust materials to withstand harsh environments and ensure long-term stability. With a pressure range of 0-100 psi (0-6.9 bar), the PGW-7200-804-P1 is suitable for a wide variety of media including air, gas, and liquids that are compatible with its wetted materials. It features a 1/4 inch NPT male process connection and a 1/2 inch NPT conduit connection for electrical wiring. The unit operates on a 10-36 VDC power supply and provides an accuracy of ±0.25% full scale, ensuring precise measurement for critical processes. This transmitter is engineered for easy installation and maintenance. Its compact design allows for mounting in tight spaces, and the zero and span adjustments are accessible for calibration. The PGW-7200-804-P1 is CE approved and meets industry standards for electromagnetic compatibility and safety. Whether used in HVAC systems, pump control, or hydraulic monitoring, this transmitter delivers consistent performance and durability. The Mercoid+Dwyer PGW-7200-804-P1 is a high-performance pressure transmitter designed for demanding industrial applications.

Basic Product Information

• 0-100 psi pressure range
• ±0.25% full scale accuracy
• 1/4 inch NPT process connection
• 10-36 VDC power supply
• Compact and robust design
• 4-20 mA analog output signal

Technical Specifications

Version & Model Difference

The PGW-7200-804-P1 is a specific configuration within the PGW series. The field label 2PDS-BA670A1 indicates a custom variant possibly for a specific OEM application. Compared to standard PGW models, this version may have a different pressure range or calibration. The PGW series includes models with various pressure ranges (e.g., 0-5 psi, 0-100 psi, 0-500 psi) and output options (4-20 mA, 0-10 VDC). The -804-P1 suffix typically denotes the electrical connection and housing options. Always verify the exact specifications against the nameplate before replacement.

Application Scenarios
