MORC Pressure Switch MSP-25R
Home > Products > MORC > Pressure Switches Need MORC MSP-25R? Pressure Switch for Hydraulic and Pneumatic Systems. Supplied with full traceability and…
Specifications
| Brand | MORC |
|---|---|
| Model Number | MSP-25R |
| Official Product Name | Pressure Switch MSP-25R |
| Applicable System | Hydraulic and Pneumatic Systems |
| Product Type | Pressure Switch |
| Equivalent Standard | CE, RoHS |
| Product Status | In Stock |
| Maximum Operating Pressure | 25 bar (362 PSI) |
| Electrical Rating | 250V AC, 5A (resistive load) |
| Contact Type | SPDT (single pole double throw) |
| Process Connection | G1/4 male thread |
| Protection Class | IP65 |
| Media Compatibility | Hydraulic oil, compressed air, neutral gases |
| Operating Temperature | -20°C to +80°C |
| Housing Material | Zinc die-cast, nickel-plated |
| Repeatability | ±1% of setpoint range |
| Adjustable Setpoint Range | 1 to 10 bar (approx.) |
Product Description
Manufactured by MORC, a recognized name in fluid power components, this switch is engineered to deliver consistent performance in hydraulic and pneumatic systems. Its robust construction ensures durability in demanding environments, making it a preferred choice for OEMs and maintenance teams alike. Featuring an adjustable setpoint range, the MSP-25R allows operators to fine-tune the switching threshold to match specific system requirements. The switch operates on a normally open (NO) or normally closed (NC) contact configuration, depending on the wiring, and is rated for electrical loads up to 250V AC. With a maximum operating pressure of 25 bar (approximately 362 PSI), it is suitable for a wide range of medium-pressure applications. The MSP-25R is designed for easy installation with a standard G1/4 thread connection, ensuring compatibility with common hydraulic and pneumatic fittings. Its compact form factor saves space in control panels and machinery, while the IP65 protection rating guards against dust and water ingress. Whether used in machine tools, packaging equipment, or process control systems, the MORC MSP-25R delivers reliable pressure sensing with minimal maintenance requirements. The MORC MSP-25R is a compact and reliable pressure switch designed for industrial automation applications requiring precise pressure monitoring and control.
Basic Product Information
- Compact design for space-saving installation
- High electrical rating up to 250V AC
- IP65 protection for industrial environments
- G1/4 thread connection for easy mounting
- Suitable for hydraulic and pneumatic media
- Adjustable setpoint range for flexible pressure control
Technical Specifications
Version & Model Difference
The MORC MSP-25R is part of the MSP series of pressure switches. Variations include different setpoint ranges (e.g., MSP-10R for lower ranges, MSP-50R for higher ranges) and electrical connection options (e.g., cable gland vs. connector). The 'R' suffix typically indicates a version with an adjustable setpoint via a knob or screw. Compared to fixed-setpoint models, the MSP-25R offers greater flexibility for applications where pressure thresholds may need to be changed during commissioning or maintenance.
Application Scenarios
