LQ057Q3DC03-61D04180A
Home > Products > Sharp > LCD Modules > LQ057Q3DC03 Need Sharp LQ057Q3DC03 (61D04180A? LCD Module for Industrial HMIs, Medical Devices, Test Equipm…
Contact us for current availability and best price of LQ057Q3DC03-61D04180A.
Specifications
| Brand | Sharp |
|---|---|
| Model Number | LQ057Q3DC03 |
| Official Product Name | 5.7" TFT LCD Module |
| Applicable System | Industrial HMIs, Medical Devices, Test Equipment |
| Product Type | LCD Module (TFT Active Matrix) |
| Equivalent Standard | RoHS Compliant |
| Product Status | In Stock |
| Resolution | 320 x 240 (QVGA) |
| Display Type | TFT Active Matrix |
| Color Depth | 6-bit, 262,144 colors |
| Brightness | 350 cd/m² (typical) |
| Contrast Ratio | 300:1 (typical) |
| Viewing Angle | Horizontal: 60° / 60°, Vertical: 40° / 60° (typical) |
| Backlight | CCFL, 1 lamp |
| Interface | 6-bit RGB parallel |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Outline Dimensions | 144.0 x 104.6 x 13.5 mm (W x H x D) |
| Display Size | 5.7 inches (diagonal) |
Product Description
It features a QVGA resolution of 320x240 pixels, delivering clear and vibrant images. The module uses an active matrix TFT display with a 6-bit color depth, capable of displaying up to 262,144 colors. Its compact size and robust construction make it suitable for a wide range of embedded systems, including human-machine interfaces (HMIs), medical devices, and test equipment. This LCD module is equipped with a cold cathode fluorescent lamp (CCFL) backlight, providing high brightness for readability in various lighting conditions. The display has a typical luminance of 350 cd/m², ensuring clear visibility even in bright environments. The module supports a 6-bit RGB interface, allowing for easy integration with a variety of controllers and processors. The viewing angle is optimized for portrait orientation, with a typical contrast ratio of 300:1. The LQ057Q3DC03 operates over a wide temperature range from -10°C to +60°C, making it suitable for industrial environments. Its storage temperature range extends from -20°C to +70°C. The module is designed with a 20-pin connector for signal input and a separate connector for the backlight. It is a reliable and durable display solution, backed by Sharp's reputation for quality and longevity. The Sharp LQ057Q3DC03 is a 5.7-inch TFT (Thin Film Transistor) LCD module designed for industrial and professional applications.
