HY-PD-05

Product Description

Home > Products > Hangyang > Photoelectric Sensors Need Hangyang HY-PD-05? Photoelectric Sensor for Industrial Automation Control Systems. Supplied with full traceability and documentation. Request a quote... Price & Availability Contact us for pricing / 询价 It operates on a 5-30VDC power supply and features an NPN open collector output, making it compatible with most PLCs and control systems. The sensor uses diffuse reflection sensing, which simplifies installation by eliminating the need for a separate reflector or receiver unit. With a detection range of up to 30 cm (adjustable), the HY-PD-05 is suitable for detecting a wide variety of objects, including opaque materials, boxes, and parts on conveyor belts. Its IP67 protection rating ensures resistance to dust and water, allowing operation in harsh industrial conditions. The sensor is equipped with a red LED indicator for output status and an adjustable sensitivity potentiometer for fine-tuning. The HY-PD-05 is housed in a durable ABS plastic enclosure with a threaded cylindrical shape (M18 x 1) for easy mounting. It supports both NPN and PNP output configurations (depending on the variant), but the standard model is NPN. The sensor is widely used in packaging machinery, material handling systems, and automated assembly lines. Its compact size and robust design make it a cost-effective solution for presence detection and position sensing tasks. The Hangyang HY-PD-05 is a compact photoelectric sensor designed for reliable object detection in industrial automation environments. Basic Product Information Wide operating voltage range: 5-30VDC, suitable for various control systems NPN open collector output, compatible with most PLCs and relays IP67 protection rating for dust and water resistance Red LED indicator for output status and sensitivity adjustment potentiometer Compact M18 threaded cylindrical housing for easy mounting Diffuse reflection sensing type with adjustable detection range up to 30 cm Technical Specifications Version & Model Difference The HY-PD-05 is available in two output configurations: NPN (model HY-PD-05N) and PNP (model HY-PD-05P). The NPN version is commonly used in Asia and with sinking PLC inputs, while the PNP version is preferred in Europe and with sourcing PLC inputs. Both versions share identical sensing characteristics and mechanical design. Additionally, some variants may offer a 4-pin M12 connector instead of the standard 2m cable, depending on the order code. Application Scenarios Can the HY-PD-05 be used with a 24VDC PLC input? Yes, the HY-PD-05 operates on 5-30VDC, so it can be directly powered from a 24VDC supply. The NPN output can sink current to the PLC input, which is typical for most PLCs. Ensure that the PLC input is configured for sinking (NPN) mode. What is the difference between NPN and PNP output versions? The NPN version (HY-PD-05N) provides a low-side switch, meaning the output transistor connects the load to ground when activated. The PNP version (HY-PD-05P) provides a high-side switch, connecting the load to the positive supply. Choose based on your control system's input configuration. Is the HY-PD-05 suitable for outdoor use? The sensor has an IP67 rating, which means it is dust-tight and protected against temporary immersion in water. However, it is not designed for continuous outdoor exposure to extreme weather conditions. For outdoor use, consider additional protection from direct sunlight and heavy rain. What is the maximum detection range of the HY-PD-05? The HY-PD-05 has an adjustable detection range of 5 to 30 cm. The actual range depends on the reflectivity of the target object; for highly reflective surfaces, the range may be longer, while dark or matte objects may require a shorter distance. Hangyang HY-PD-06 Photoelectric Sensor (HY-PD-06) Hangyang HY-40SL-B19 PLC Module (HY-40SL-B19)
