East Electric Control Board HANL100018R1 use for 8E/4
Other Brands
East Electric Control Board HANL100018R1 use for 8E/4
Home > Products > East Electric > VFD Control Board Need East Electric HANL100018R1 use for 8E/4? Control Board for East Electric 8E/4 series VFD. Sup…
Specifications
| Brand | East Electric |
|---|---|
| Model Number | HANL100018R1 |
| Official Product Name | VFD Control Board (for 8E/4 series) |
| Applicable System | East Electric 8E/4 series VFD |
| Product Type | Control Board |
| Equivalent Standard | OEM Original |
| Product Status | In Stock |
| Analog Inputs | 2 channels (0-10V, 4-20mA) |
| Digital Inputs | 6 channels (24V DC) |
| Digital Outputs | 2 relay outputs (250V AC/3A) |
| Communication Interface | RS485 (Modbus RTU) |
| Power Supply | 24V DC (from main board) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 200mm x 150mm x 30mm (approx.) |
| Weight | 0.5 kg (approx.) |
| Control Mode | V/f, Sensorless Vector, Closed-loop Vector |
Product Description
This board serves as the central processing unit, managing motor control algorithms, I/O signals, and communication interfaces. It is engineered to provide precise speed and torque control for industrial AC motors, ensuring reliable and efficient operation in demanding environments. This control board features a high-performance microcontroller, robust power supply circuitry, and isolated I/O channels to protect against electrical noise and surges. It supports multiple control modes including V/f, sensorless vector control, and closed-loop vector control, making it versatile for various applications. The board is designed for easy integration into existing 8E/4 drive systems, with plug-in connectors and standardized mounting holes. Manufactured to East Electric's strict quality standards, the HANL100018R1 undergoes rigorous testing to ensure long-term reliability. It is a genuine OEM spare part, ensuring compatibility and performance. Whether for replacement or system upgrade, this control board is essential for maintaining optimal VFD performance in industrial automation, HVAC, pumping, and conveyor applications. The East Electric HANL100018R1 is a specialized control board designed for use in East Electric's 8E/4 series variable frequency drives (VFDs).
Basic Product Information
- Supports V/f, sensorless vector, and closed-loop vector control modes
- Isolated I/O channels for noise immunity
- Plug-in connectors for easy installation
- Compatible with East Electric 8E/4 series VFDs
- Rigorous testing for industrial reliability
- High-performance microcontroller for precise motor control
Technical Specifications
Version & Model Difference
The HANL100018R1 is a specific revision of the control board used in the 8E/4 series. Earlier versions (e.g., HANL100018R0) may have had fewer I/O channels or lacked certain communication protocols. This R1 version adds an extra analog input and improved EMC filtering. It is backward compatible with existing 8E/4 drives, but firmware updates may be required for full functionality.
Application Scenarios
- East Electric GLBS 300 530P1 8E-24E Drawer Backboards
- East Electric GLBS 200 523R2 (32A x 3) 8E/2 Plug-in Backboards
- East Electric GLBS 200 523R5 (63A x 3) 8E/2 Plug-in Backboards
- East Electric SY J-6-32.3 Connector with Lead (324)
- East Electric SY 1-6-32.5 Connector with Lead (324)
- East Electric SY J-16-63.3 Connector with Lead (63A)
- East Electric (HANL 100 019R1)+(MNS-3-027P1) Small Interlock with Pedestals
- East Electric HANL 200 003P1 Instrument Board (Front Plate) for Withdrawable Circuit Breaker Unit Type 8E-24E
