Specifications
| Brand | Kunlun Fuji |
|---|---|
| Model Number | FKCW35V5-LSCBY-BA |
| Official Product Name | Differential Pressure Transmitter (Flow) |
| Applicable System | Flow measurement systems using differential pressure method |
| Product Type | Transmitter (field instrument) |
| Equivalent Standard | LFN331W3-YB |
| Product Status | Active |
| Lifecycle note | Active, available for order |
| Process Connection | 1/2NPT(F) |
| Output Signal | DC 4-20mA + HART |
| Supply Voltage | DC 10.5-45V |
| Accuracy | +/-0.075% of span |
| Stability | +/-0.1% of URL per year |
| Ambient Temperature Limit | -40 to +85 degC |
| Process Temperature Limit | -40 to 120 degC |
| Enclosure Rating | IP67 (equiv. IEC / JIS C 0920) |
| Wetted Parts Material | 316L stainless steel (standard) |
| Housing Material | Aluminum alloy with polyester coating |
| Certifications | ATEX, FM, CSA, TIIS, CE |
| Measurement Range | Exact model not confirmed |
Product Description
Need 昆仑富士 FKCW35V5-LSCBY-BA/ LFN331W3-YB (Process connection 1/2 NPT(F))? Transmitter for Flow measurement systems using differential pressure method....
Basic Product Information
- Process connection: 1/2NPT(F) for easy installation
- Output: 4-20mA DC with HART protocol (optional)
- Rugged construction for harsh industrial environments
- Local zero and span adjustment
- Wide turndown ratio for flexible range setting
- Measures differential pressure for flow applications with high accuracy
Technical Specifications
Version & Model Difference
The FKCW35V5-LSCBY-BA is a specific configuration of the Kunlun Fuji differential pressure transmitter series. It is equivalent to the Fuji LFN331W3-YB model. The 'LSCBY' suffix indicates the process connection and material options. The 'BA' suffix may denote a specific output or option. The inquiry model FKCW35V5-LKCBY-AA includes a manifold valve, while the FKCW35V5-LSCBY-BA does not. The measurement range for the inquiry is 0-1 bar, but other ranges are available.
Application Scenarios
- Flow measurement of liquids, gases, and steam in pipelines
- Level measurement in closed tanks using differential pressure
- Filter monitoring and pump protection in industrial processes
- Energy management systems in power plants
- Chemical and petrochemical process control
- Water and wastewater treatment plants
