Jinbo Marine Analog AC Voltmeter F96-ACB-V
F96-ACB-V
Other Brands
Jinbo Marine Analog AC Voltmeter F96-ACB-V
Home > JINBO Marine > Analog Panel Meter > F96-ACB-V Need Jinbo Marine F96-ACB-V? Analog AC Voltmeter for Marine and industrial switchboard / distribu…
Specifications
| Brand | JINBO Marine |
|---|---|
| Model Number | F96-ACB-V |
| Official Product Name | Voltmeter (Right Angle Meter) |
| Applicable System | Marine and industrial switchboard / distribution panels |
| Product Type | Analog AC Voltmeter (Right-Angle Panel Meter) |
| Equivalent Standard | GB/T7676-1998 (equivalent to IEC 60051) |
| Product Status | In Stock |
| Accuracy Class | 1.5 (special order 1.0) |
| Scale Deflection | 250 degrees (right-angle type) |
| Standard | GB/T7676-1998 (equivalent to IEC 60051) |
| Case Size (L x W x D) | 96 x 96 x 108 mm |
| Panel Cutout | 92 x 92 mm |
| Frequency | 50/60 Hz |
| Operating Temperature | -10 to +50 C (AC meter 0 to 40 C) |
| Mounting | Vertical, panel flush |
| Measuring Range | 0 to 300 V AC (direct; higher ranges via potential transformer) |
Product Description
It measures AC voltage on a printed dial with a 250-degree pointer deflection for clear readability. Manufactured to GB/T7676-1998 (equivalent to IEC 60051), the moving element uses a taut-band suspension with no friction, giving reliable operation and strong resistance to mechanical shock and vibration. The black case with a white dial and vertical mounting fits standard marine electrical enclosures. The JINBO Marine F96-ACB-V is a right-angle (90-degree) analog AC voltmeter housed in a 96x96 mm square case, built for shipboard and industrial switchboard panels.
Basic Product Information
- Taut-band (moving-coil) suspension mechanism with no friction, shock and vibration resistant
- 96x96 mm square case with 92x92 mm panel cutout
- Printed dial, black case and white dial, vertical mounting
- Conforms to GB/T7676-1998 (IEC 60051), suitable for 50/60 Hz systems
- Right-angle (90-degree) pointer with 250-degree scale sweep for high readability
Technical Specifications
Version & Model Difference
The F96-ACB family shares the same 96x96 mm right-angle case; the suffix defines the measured quantity. '-V' is the AC voltmeter (direct up to 600 V, higher via PT), while '-A' is the AC ammeter (direct up to 50 A, higher via current transformer with 5 A or 1 A secondary). Both meet GB/T7676-1998 and share identical cutout and outline dimensions.
Application Scenarios
- Shipboard main and auxiliary switchboards
- Generator and power distribution panels
- Industrial motor control centers and substations
- Offshore and marine electrical instrumentation
- Jinbo Marine F96-ACB-A AC Ammeter (Right-Angle Panel Meter)
- Jinbo Marine F96-ACB AC Ammeter (F96-ACB)
Frequently Asked Questions
What is the measuring range of the F96-ACB-V?
It is specified as a 0-300V AC voltmeter; the F96-ACB voltmeter platform also covers 10V-600V direct and higher ranges via potential transformer.
Which standard does it comply with?
GB/T7676-1998, equivalent to the international IEC 60051 standard for direct-acting indicating analog instruments.
What panel cutout is required?
A 92 x 92 mm square cutout; the bezel outline is 96 x 96 mm with 108 mm depth.
Can it be used on both 50 Hz and 60 Hz systems?
Yes, the F96-ACB AC voltmeter is suitable for both 50 Hz and 60 Hz supplies.
Need F96-ACB-V?
Get a Quote in Minutes.
12-month warranty · No MOQ · Worldwide shipping with tracking
Request a Quote
Get the latest price, stock status and bulk order discount for F96-ACB-V. Our team replies within 30 minutes (working hours).
