Home > Products > Finder > Relay Interface Modules Need Finder 95.02? Relay Interface Module for Industrial control panels, PLC interfaces, building a…
Specifications
| Brand | Finder |
|---|---|
| Model Number | 95.02 |
| Official Product Name | Relay Interface Module 95.02 |
| Applicable System | Industrial control panels, PLC interfaces, building automation |
| Product Type | Relay Interface Module |
| Equivalent Standard | IEC 61810, EN 61810 |
| Product Status | In Stock |
| Contact Configuration | 2 CO (DPDT) |
| Contact Material | AgNi + Au (gold-plated) |
| Rated Switching Voltage | 250 V AC / 220 V DC |
| Rated Current | 8 A (AC1) |
| Switching Capacity (AC1) | 2000 VA |
| Switching Capacity (DC1) | 192 W (24V), 90 W (48V), 60 W (110V) |
| Coil Power Consumption | 0.5 W |
| Mechanical Life | >10 million operations |
| Electrical Life (AC1) | >100,000 operations at 8A, 250V |
| Dielectric Strength | 4 kV between coil and contacts |
| Operating Temperature | -40°C to +70°C |
| Protection Degree | IP20 |
| Mounting | DIN rail (35mm) |
| Width | 15.6 mm |
| Coil Voltage | 24 V DC |
Product Description
It features two changeover (CO) contacts, providing flexibility for various circuit configurations. The module is part of the Finder 95 series, known for its robust construction and ease of installation on standard DIN rails. This relay module operates with a coil voltage of 24V DC, making it suitable for modern PLC and electronic control systems. It includes a green LED indicator for coil status, ensuring quick visual diagnostics. The module's screw terminals accept wires up to 2.5 mm², simplifying wiring and maintenance. With a mechanical life of over 10 million operations, the 95.02 ensures long-term reliability in demanding applications. The Finder 95.02 is designed for use in industrial automation, process control, and building management systems. Its compact footprint (15.6 mm width) allows for high-density mounting, saving valuable cabinet space. The module is also available with optional protection circuits, such as freewheeling diodes or RC networks, to extend coil life when switching inductive loads. This product is a genuine OEM spare part, ensuring compatibility and performance. The Finder 95.02 is a compact relay interface module designed for industrial control systems, offering reliable switching of loads up to 8A.
Basic Product Information
- 24V DC coil with LED indication
- Compact 15.6mm width for DIN rail mounting
- Screw terminals accepting up to 2.5 mm² wires
- Mechanical life >10 million operations
- Optional coil protection (freewheeling diode, RC network)
- 2 changeover (CO) contacts with 8A switching capacity
Technical Specifications
Version & Model Difference
The Finder 95 series includes several versions with different coil voltages (e.g., 12V DC, 24V DC, 48V DC, 110V AC/DC, 230V AC) and contact configurations (1 CO, 2 CO, 3 CO). The 95.02 specifically denotes a 2 CO version with 24V DC coil. Other variants like 95.01 (1 CO) and 95.03 (3 CO) are available. Additionally, versions with integrated protection circuits (e.g., 95.02.0 with diode, 95.02.1 with RC network) are offered for inductive load switching.
