PILZ Safety relay 774314
Home > Pilz > Safety Relays > 774314 Need PILZ 774314? Safety relay for Machine / plant safety. Supplied with full traceability and documentation. Req…
Specifications
| Brand | Pilz |
|---|---|
| Model Number | 774314 |
| Official Product Name | PNOZ X3 Safety Relay (774314) |
| Applicable System | Machine / plant safety (E-STOP, safety gates) |
| Product Type | Safety relay (standalone) |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Supply Voltage | 110 V AC / 24 V DC |
| Outputs | 3 N/O, 1 N/C, 1 SC (semiconductor) |
| Rated Current | 8 A (safety contacts) |
| Contact Material | AgSnO2 (silver tin oxide) |
| Width | 45 mm |
| Connection | Screw terminals (integrated) |
| Mounting | DIN rail |
| Inputs | 1/2-channel wiring, short-circuit detection |
| Monitoring | E-STOP, safety gates |
| Start Mode | Automatic / monitored start |
| Protection | IP20 (housing) |
| Series | PNOZ X3 |
Product Description
It accepts 110 V AC / 24 V DC supply and provides 3 normally-open, 1 normally-closed and 1 semiconductor (SC) output. With automatic or monitored start and 1/2-channel wiring with short-circuit detection, it meets high safety-category requirements while occupying a compact 45 mm DIN-rail width. Pilz 774314 is a standalone PNOZ X3 safety relay that monitors emergency-stop and safety-gate circuits in machinery and plant safety systems.
Basic Product Information
- Outputs: 3 N/O, 1 N/C, 1 semiconductor (SC)
- 1/2-channel wiring with contact short-circuit detection
- Automatic or monitored start; monitors E-STOP and safety gates
- Supply 110 V AC / 24 V DC, compact 45 mm DIN-rail width
Technical Specifications
Version & Model Difference
774314 is the PNOZ X3 variant with 110 V AC / 24 V DC supply and 3 N/O + 1 N/C + 1 SC outputs. Other PNOZ X series numbers differ by supply voltage, contact count or start behaviour; verify the exact PNOZ X variant before substitution.
Application Scenarios
- Emergency-stop (E-STOP) circuit monitoring
- Safety gate and guard interlocking
- Machine and plant protective-stop systems
- PILZ PNOZ S3 750 103 Safety Relay
Frequently Asked Questions
What supply voltage does Pilz 774314 use?
It operates on 110 V AC and 24 V DC simultaneously (UB 110 V AC / 24 V DC) with integrated screw terminals.
What outputs does the relay provide?
It provides 3 normally-open, 1 normally-closed and 1 semiconductor (SC) output, rated 8 A on the safety contacts.
What safety functions does it monitor?
It monitors emergency-stop and safety-gate circuits with 1/2-channel wiring and short-circuit detection across contacts.
How is it mounted and started?
It mounts on a standard DIN rail in a 45 mm-wide housing and supports automatic or monitored start; contact us for exact specifications on variants.
Need 774314-relay?
Get a Quote in Minutes.
12-month warranty · No MOQ · Worldwide shipping with tracking
Request a Quote
Get the latest price, stock status and bulk order discount for 774314-relay. Our team replies within 30 minutes (working hours).
