560CMR01--1KGT022200R0001

Product Description

It integrates advanced microprocessor-based protection functions with reliable communication capabilities, ensuring robust monitoring and control of electrical networks. This module is part of the ABB+Hitachi collaboration, combining ABB's expertise in power and automation with Hitachi's high-quality manufacturing standards, resulting in a product that meets international safety and performance norms. Engineered for demanding environments, the 560CMR01 offers comprehensive protection schemes including overcurrent, earth fault, and undervoltage protection. It features multiple setting groups, enabling flexible adaptation to different system configurations. The module supports Modbus RTU and IEC 61850 communication protocols, facilitating seamless integration into modern SCADA systems. Its robust design ensures reliable operation in temperatures ranging from -25°C to +70°C, making it suitable for harsh industrial settings. The 560CMR01 is housed in a compact, panel-mount enclosure with a user-friendly interface, including a backlit LCD display and keypad for local configuration. It provides extensive event logging and fault recording capabilities, aiding in post-fault analysis and system diagnostics. With its high accuracy and fast response times, this protection relay module is an ideal choice for utilities, manufacturing plants, and infrastructure projects requiring dependable electrical protection. The ABB+Hitachi 560CMR01 (1KGT022200R0001) is a sophisticated protection relay module designed for high-voltage and medium-voltage applications in industrial power systems.

Basic Product Information

• Multiple protection functions: overcurrent, earth fault, undervoltage
• Supports Modbus RTU and IEC 61850 communication protocols
• User-friendly interface with backlit LCD and keypad
• Wide operating temperature range (-25°C to +70°C)
• Comprehensive event logging and fault recording
• Advanced microprocessor-based protection algorithms

Technical Specifications

Version & Model Difference

The 560CMR01 is part of the 560 series, which includes variants like 560CMR02 and 560CMR03. The main differences lie in the number of protection functions and communication options. The 560CMR01 offers a standard set of protection functions and supports Modbus RTU and IEC 61850, while higher models may include additional functions like distance protection or transformer differential protection. Hardware revisions (e.g., Rev A, B) may have updated components but maintain the same form and fit.

Application Scenarios

• ABB 560PSU01 RTU560 Power Supply Module
• ABB 560RTC03 RTU560 Real Time Clock Module
• ABB 560CMR01 RTU560 Communication Module
