Home > Products > Hengli > Proportional Directional Valve Need Hengli 4WRPEH6C4B40L-20/G24K0/A1M? Proportional Directional Valve for Hydraulic control…
Contact us for current availability and best price of 4WRPEH6C4B40L-20G24K0A1M.
Specifications
| Brand | Hengli |
|---|---|
| Model Number | 4WRPEH6C4B40L-20/G24K0/A1M |
| Official Product Name | Proportional Directional Valve, direct operated, with integrated electronics |
| Applicable System | Hydraulic control systems |
| Product Type | Proportional Directional Valve |
| Equivalent Standard | ISO 4401-03-02-0-05 (NG6) |
| Product Status | In Stock |
| Max operating pressure | 350 bar (5000 psi) |
| Max flow | Up to 80 L/min (depending on spool) |
| Supply voltage | 24V DC (G24) |
| Command signal | 0 to 10V or 4 to 20mA (selectable) |
| Hysteresis | < 0.2% |
| Repeatability | < 0.1% |
| Step response time | 10-20 ms (depending on stroke) |
| Ambient temperature range | -20°C to +60°C |
| Hydraulic fluid temperature range | -20°C to +80°C |
| Viscosity range | 2.8 to 500 mm²/s |
| Mounting interface | ISO 4401-03-02-0-05 |
| Size | NG6 (CETOP 03) |
Product Description
This valve is part of the 4WRPEH series, which features a direct-operated, spool-type design with integrated electronic control. It is suitable for applications requiring accurate positioning, velocity, and force control, such as machine tools, injection molding machines, and test rigs. The valve operates with a nominal size of 6 (NG6) and conforms to ISO 4401-03-02-0-05 mounting patterns, ensuring easy interchangeability with similar valves from other manufacturers. The Hengli 4WRPEH6C4B40L-20/G24K0/A1M is a high-performance proportional directional valve designed for precise control of flow and direction in hydraulic systems.
Basic Product Information
- Integrated electronics (OBE) for simplified wiring and control
- High dynamic response with low hysteresis
- NG6 mounting interface per ISO 4401
- Various spool types available for different flow characteristics
- 12V or 24V DC supply options
- Command signal via differential input or PLC
- LED status indication for diagnostics
- Direct operated proportional directional spool valve
Technical Specifications
Version & Model Difference
The model 4WRPEH6C4B40L-20/G24K0/A1M includes a specific spool type (C4) and a 24V DC coil with integrated electronics. Other versions may have different spool symbols (e.g., C5, C6) or supply voltages (e.g., G12 for 12V DC). The '-20' indicates the series number, which may reflect minor design updates. The 'A1M' suffix typically denotes the command signal configuration (e.g., 0-10V or 4-20mA). Always verify the exact model code for your application.
Application Scenarios
- Hengli 4WRPEH6C4B12L-31/M/24A1 Proportional Directional Valve (4WRPEH6C4B12L-31/M/24A1)
