Mean Well DIN Rail AC 1DRT-24
Home > Mean Well > DIN Rail Power Supplies > 1DRT-24 Need Mean Well 1DRT-24? DIN Rail AC for Industrial Control Cabinet / Factory Automation. Supplied…
Specifications
| Brand | Mean Well |
|---|---|
| Model Number | 1DRT-24 |
| Official Product Name | 1DRT-24 24V DIN Rail Power Supply |
| Applicable System | Industrial Control Cabinet / Factory Automation |
| Product Type | DIN Rail AC/DC Power Supply |
| Equivalent Standard | Contact us for cross-reference and alternative models |
| Product Status | In Stock |
| Output Current | 10 A |
| Output Power | 240 W |
| Input Voltage | 3-phase 340-550 VAC, 47-63 Hz |
| Efficiency | 89% |
| Cooling | Free air convection (fanless) |
| Protections | Short circuit / Overload / Over voltage / Over temperature |
| Mounting | DIN rail TS-35/7.5 or 15 |
| Operating Temperature | -20 C to +70 C |
| Dimensions | 125.5 x 125.2 x 100 mm |
| Approvals | UL 508, EN 60950 / EN 62368, CE |
| Warranty | 3 years |
| Output Voltage | 24 VDC (adjustable 24-28 V) |
Product Description
Based on the MEAN WELL DRT series, it delivers 240 W with free-air convection cooling and comprehensive protection against short circuit, overload, over voltage and over temperature. Its narrow DIN-rail profile and UL 508 / EN 60950 approvals make it a fit for factory automation, semiconductor and electromechanical equipment. Mean Well 1DRT-24 is a metal-housing DIN rail power supply that converts 3-phase 340-550 VAC input into a stabilized 24 VDC / 10 A output for industrial control cabinets.
Basic Product Information
- 240 W output, 10 A, free-air convection cooling (fanless)
- Protections: short circuit, overload, over voltage, over temperature
- UL 508 and EN 60950/EN 62368 approved, DIN rail TS-35 mount
- 3-phase 340-550 VAC input with 24-28 VDC adjustable output
Technical Specifications
Version & Model Difference
The catalog model '1DRT-24' corresponds to the MEAN WELL DRT-240-24 (240 W, 24 V) three-phase DIN rail series; the '240' denotes wattage and '24' the 24 V output. Newer replacement is the TDR-240-24. Confirm exact suffix with us for cross-reference.
Application Scenarios
- Factory automation and control cabinet power distribution
- Semiconductor fabrication and electromechanical equipment
- Marine and industrial DIN-rail DC power supply
- Mean Well NES-100-24 Enclosed Switching Power Supply 24V 108W
- Mean Well 24V 25A 600W Enclosed Switching Power Supply
- Mean Well MDR-20-12 20W 12V DIN Rail Switching Power Supply
- Mean Well QYL-1000-15 Switching Power Supply
- Mean Well WDR-240-24 24V 10A Industrial DIN Rail Power Supply
- MEAN WELL NDR-480-24 DIN Rail Power Supply 480W 24V
- MEAN WELL NDR-240-24 DIN Rail Power Supply 240W 24V
- MEAN WELL EDR-120-24 Slim DIN Rail Power Supply 120W 24V
Frequently Asked Questions
What input and output does the 1DRT-24 provide?
It is a 3-phase DIN rail supply accepting 340-550 VAC input and delivering a stabilized 24 VDC output at 10 A (240 W), adjustable from 24 to 28 V.
How is it cooled and protected?
Cooling is by free-air convection (fanless) for long life, with built-in protection against short circuit, overload, over voltage and over temperature.
Which safety approvals apply?
The unit is approved to UL 508 and EN 60950 / EN 62368 with CE marking, suitable for industrial control equipment.
Is there a newer replacement model?
MEAN WELL lists the TDR-240-24 as the successor to the DRT-240-24; contact us to confirm the exact 1DRT-24 suffix and cross-reference options.
