LS Thermal Overload Relay RELAY,MT-32(9-13A),LS
Home / Products / Motor Protection / LS Electric MT-32 9-13A Thermal Overload Relay Need LS RELAY,MT-32(9-13A),LS? Thermal Overload Relay for Motor control / L…
Specifications
| Brand | LS Electric |
|---|---|
| Model Number | MT-32 9-13A |
| Official Product Name | MT-32 9-13A Thermal Overload Relay |
| Applicable System | Motor control / LS MC series contactor assemblies |
| Product Type | Thermal Overload Relay |
| Equivalent Standard | IEC 60947-4-1 |
| Product Status | Available on request |
| Series | METASOL MT series |
| Current Adjustment Range | 9 to 13 A |
| Auxiliary Contacts | 1 NO + 1 NC |
| Connection | Screw clamp terminals |
| Trip Class | Class 10A |
| Operating Temperature | -5 to 60 deg C |
| Protection Rating | IP20 |
| Compatible Contactors | LS MC-9b to MC-22b, MC-32a to MC-40a |
| Rated Operational Voltage | Available on request |
| Approx. Weight | Approx. 173 g |
| Product Type | Thermal overload relay (bimetal type) |
Product Description
It mounts directly onto compatible LS contactors and provides an adjustable overcurrent range of 9 to 13 A. With integrated 1 NO + 1 NC auxiliary contacts, screw-clamp terminations and an IP20 sealed structure, the MT-32 delivers reliable, arc-free protection for panel builders and maintenance teams. The compact body supports DIN-rail and on-contactor mounting, simplifying wiring and reducing panel space. The LS Electric MT-32 9-13A is a bimetal-type thermal overload relay from the METASOL MT series, designed to protect AC motors and circuits against overloads, phase failure, long starting times and prolonged stalling.
Basic Product Information
- Integrated 1 NO + 1 NC auxiliary contacts for alarm and control circuits
- Direct on-contactor mounting with LS MC-9b to MC-22b and MC-32a to MC-40a contactors
- Screw-clamp terminals and sealed IP20 structure for safe, easy wiring
- Ambient temperature compensation for stable tripping from -5 to 60 deg C
- Adjustable overcurrent setting range of 9 to 13 A for precise motor matching
Technical Specifications
Version & Model Difference
The MT-32 family spans multiple current frames (e.g. 9-13A, 12-18A, 15A) that share the same METASOL footprint and on-contactor mounting but differ in adjustment range and compatible contactor frames. Select the frame whose current range matches the motor full-load current.
Application Scenarios
- Overload and phase-failure protection for three-phase AC motors
- Motor starters in HVAC, pumps, conveyors and machine tools
- Industrial control panels and distribution boards
- LS RKN 3P+N 40A 30mA Residual Current Circuit Breaker (RCCB)
- LS 40A 30mA RKN 3P+N Residual Current Circuit Breaker (RKN4030)
- LS Metasol MC-12A Magnetic Contactor, AC 220 V Coil
- LS MC-12A 24VDC PLC Controller (MC-12A)
- LS MC-18A 220VAC Magnetic Contactor (MC-18A)
- LS MC-18A 24VDC PLC Module (MC-18A 24VDC)
- LS MC-6A 220VAC Contactor (MC-6A 220VAC)
Frequently Asked Questions
What current range does the LS MT-32 9-13A cover?
The adjustment range is 9 to 13 A, suitable for protecting smaller AC motors whose full-load current falls within this band.
Which LS contactors does this overload relay mount to?
It mounts directly onto LS MC-9b to MC-22b and MC-32a to MC-40a contactors in the METASOL MC series via the standard on-contactor adapter.
Does the MT-32 9-13A include auxiliary contacts?
Yes. It integrates 1 normally-open and 1 normally-closed auxiliary contact for alarm or control-circuit signalling.
What protection rating and temperature range apply?
The relay is sealed to IP20 and operates from -5 to 60 deg C with ambient temperature compensation for stable tripping.
