HIMA Safety digital output module F3330
['Home', 'Functional Safety', 'Safety I/O', 'HIMA HIMatrix', 'F3330'] Need HIMA F3330? Safety digital output …
Specifications
| Brand | HIMA |
|---|---|
| Model Number | F3330 |
| Official Product Name | 8-Channel Safety Digital Output Module |
| Applicable System | HIMA HIMatrix / HIMax / HiMAT safety systems |
| Product Type | Safety digital output module |
| Equivalent Standard | Contact supplier for cross-reference and alternative models |
| Product Status | Active |
| Lifecycle note | Commercialized |
| Output voltage | 24 V DC |
| Max. current per channel | 500 mA |
| Load capability | 12 W inductive / 4 W lamp (per channel) |
| Max. line resistance | 11 Ohm (per output circuit) |
| Internal drop | 2 V at 500 mA |
| Undervoltage trip | < 16 V DC |
| Format | 4 TE |
| Certifications | SIL 3 (IEC 61508), ATEX Zone 2 |
| Weight | approx. 0.1 kg |
| Channels | 8 safety digital outputs |
Product Description
Basic Product Information
- 24 V DC output, 500 mA per channel (max)
- Short-circuit protection and line/resistance monitoring
- SIL 3 certified (IEC 61508), fail-safe design
- Compact 4 TE width, hot-swappable with readback diagnostics
- 8 independent safety digital output channels
Technical Specifications
Version & Model Difference
['F3330 is the 8-channel 4 TE safety DO; the F3322 is a higher-density 16-channel variant in the same family.', 'Used across HIMatrix, HIMax and HiMAT platforms with appropriate backplane/cable (e.g. Z7138 use).']
Application Scenarios
- ESD emergency shutdown solenoid valve drive
- Burner management and fire & gas outputs
- Oil & gas, chemical and power plant safety loops
