PEA-M5A-controller
Hanyoung Temperature Controller PEA-M5A
Hanyoung
Hanyoung Temperature Controller PEA-M5A
Home > Products > Hanyoung > Temperature Controllers Need Hanyoung PEA-M5A? Temperature Controller for Industrial temperature control systems. Supplie…
Contact us for current availability and best price of PEA-M5A-controller.
Specifications
| Brand | Hanyoung |
|---|---|
| Model Number | PEA-M5A |
| Official Product Name | Digital Temperature Controller |
| Applicable System | Industrial temperature control systems |
| Product Type | Temperature Controller |
| Equivalent Standard | DIN 1/16 (48x48mm) |
| Product Status | In Stock |
| Input Type | Thermocouple K, J, E, T, R, S, B; RTD Pt100; DC voltage/current |
| Control Output | Relay SPDT 5A/250VAC |
| Power Supply | 100-240VAC, 50/60Hz |
| Display | Dual 4-digit LED (PV: red, SV: green) |
| Control Method | ON/OFF or PID with auto-tuning |
| Alarm Output | Optional (depending on model suffix) |
| Protection Rating | IP65 (front panel) |
| Operating Temperature | 0 to 50°C |
| Storage Temperature | -20 to 60°C |
| Mounting | Panel mount, depth 80mm |
| Weight | Approx. 150g |
| Size (DIN) | 1/16 DIN (48 x 48 mm) |
Product Description
It features a universal input that accepts thermocouples (K, J, E, T, R, S, B), RTDs (Pt100), and linear current/voltage signals, making it versatile for various sensors. The controller offers a dual display (PV/SV) with a clear LED readout, and its front panel is IP65-rated for protection against dust and water jets. Equipped with a relay output rated at 5A/250VAC, the PEA-M5A can directly control heaters, solenoids, or contactors. It supports both ON/OFF and PID control modes, with auto-tuning functionality to optimize control parameters automatically. The unit operates on a universal power supply of 100-240VAC, ensuring compatibility with global electrical systems. Safety and reliability are emphasized with features like heater break alarm, input error indication, and a lock function to prevent unauthorized parameter changes. The controller is housed in a flame-retardant case and is designed for panel mounting with a depth of only 80mm, saving valuable cabinet space. With its robust construction and advanced features, the PEA-M5A is suitable for plastic molding, packaging machinery, ovens, and environmental chambers. The Hanyoung PEA-M5A is a compact 1/16 DIN digital temperature controller designed for precise temperature regulation in industrial processes.
Basic Product Information
- Dual LED display for PV (process value) and SV (set value)
- PID control with auto-tuning and manual tuning options
- Relay output: 5A/250VAC, SPDT
- Universal power supply: 100-240VAC, 50/60Hz
- IP65 front panel protection
- Heater break alarm and input error indication
- Parameter lock function for security
- Universal input: thermocouple (K, J, E, T, R, S, B), RTD (Pt100), linear current/voltage
Technical Specifications
Version & Model Difference
The PEA-M5A is part of Hanyoung's PEA series. The 'M' indicates a basic model with relay output. Other versions include PEA-M5B (with alarm output), PEA-M5C (with RS485 communication), and PEA-M5D (with both alarm and communication). The PEA-M5A is the standard model without additional options. All versions share the same base features and input flexibility.
Application Scenarios
- Hanyoung HY-L804 Door Switch
- Hanyoung HY-L804 Temperature Controller (HY-L804)
