GE Analog input module ic693alg392
Home > GE > Series 90-30 > IC693ALG392 Need GE ic693alg392? Analog input module for GE Fanuc Series 90-30 PLC racks. Supplied with full traceability a…
Contact us for current availability and best price of ic693alg392.
Specifications
| Brand | GE |
|---|---|
| Model Number | IC693ALG392 |
| Official Product Name | GE Fanuc Series 90-30 analog input module, 8 differential channels, voltage / current |
| Applicable System | GE Fanuc Series 90-30 PLC racks |
| Product Type | Analog input module (PLC I/O) |
| Equivalent Standard | Series 90-30 PLC standard; revisions IC693ALG392A / B / BD / BE listed by suppliers |
| Product Status | Discontinued / Legacy (Series 90-30 platform) |
| Number of channels | 8 differential |
| Voltage input ranges | 0 to 10 V, -10 to 10 V, -5 to 5 V, 0 to 5 V |
| Current input ranges | 0 to 20 mA, 4 to 20 mA |
| Input impedance | Voltage greater than 100 kohm (one source lists greater than 1 Mohm); current 250 ohm internal |
| Resolution | N/A (distributor listings state 12-bit and 16-bit) |
| Accuracy | N/A (listings state +/-0.1 percent to +/-0.25 percent of full scale) |
| Isolation | N/A (distributor data varies) |
| External supply voltage | 20 to 30 V DC |
| Internal supply | 5 V DC from PLC backplane |
| Operating temperature | 0 to 60 deg C |
| Weight | Approx. 0.3 kg |
| Programming | Logicmaster 90-30 / Proficy Machine Edition; %AI register mapping |
| Module type | Analog input module |
Product Description
It provides eight differential analog input channels that accept standard industrial voltage and current signals from sensors and transmitters, including 0 to 10 V, -10 to 10 V, -5 to 5 V, 0 to 5 V, 0 to 20 mA and 4 to 20 mA ranges. The module is wired to a Series 90-30 rack position and is configured with Logicmaster 90-30 or Proficy Machine Edition software, with channel data mapped into the %AI analog input registers. The Series 90-30 platform is a legacy control system and this module is supplied as a spare part for maintenance and modernization of installed equipment. Note: distributor listings disagree on the module conversion resolution (12-bit versus 16-bit), so the exact resolution should be confirmed against the GE datasheet for your hardware revision. The GE IC693ALG392 is an analog input module for the GE Fanuc Series 90-30 programmable logic controller family.
Basic Product Information
- Configurable input ranges: 0 to 10 V, -10 to 10 V, -5 to 5 V, 0 to 5 V, 0 to 20 mA and 4 to 20 mA
- Differential inputs reduce noise for signal integrity in electrically noisy environments
- Internal 250 ohm resistor simplifies 4 to 20 mA current loop wiring
- Front panel LED indicators for module and channel status
- Eight differential analog input channels for voltage and current signals
Technical Specifications
Version & Model Difference
Suppliers list several hardware revisions of the module, including IC693ALG392A, IC693ALG392B, IC693ALG392BD and IC693ALG392BE. Revision differences affect marking and potentially conversion behavior; distributor data also conflicts on resolution (12-bit versus 16-bit). Confirm the exact revision and resolution against the GE datasheet for your installed base before ordering.
