159590-cylinder

Product Description

This double-acting cylinder features a 50 mm bore and a 100 mm stroke, delivering a theoretical force of 1178 N at 6 bar (return stroke 990 N). It is designed to ISO 15552 (formerly VDMA 24562) standards, ensuring interchangeability with other manufacturers' cylinders of similar specifications. The cylinder's robust extruded aluminum barrel and hard-anodized surfaces provide excellent corrosion resistance and durability in demanding environments. The DNC-50-100-PPV-A incorporates adjustable end-position cushioning (PPV) to absorb kinetic energy and reduce noise and vibration at stroke ends, extending the cylinder's service life. It operates within a pressure range of 1 to 12 bar and can function in temperatures from -20°C to +80°C, making it suitable for a wide range of applications. The piston rod is made of high-alloy steel with a hard chrome finish, ensuring low friction and high wear resistance. The cylinder is equipped with standard ports (G1/4) and can be fitted with a variety of accessories such as proximity sensors, mounting brackets, and rod end couplings. This cylinder is widely used in material handling, packaging machinery, pick-and-place units, and general automation tasks. Its modular design allows for easy maintenance and customization, with options for through piston rod, different stroke lengths, and various mounting configurations. The Festo 159590 is a genuine OEM part, ensuring perfect fit and performance. It is available as a new original unit, backed by Festo's quality assurance and a standard warranty, making it a reliable choice for both OEM and aftermarket applications. The Festo 159590 is a DNC-50-100-PPV-A pneumatic cylinder, part of the renowned DNC series known for its reliability and versatility in industrial automation.

Basic Product Information

• Adjustable end-position cushioning (PPV) for smooth deceleration
• ISO 15552 compliant for interchangeability
• Extruded aluminum barrel with hard-anodized surface for corrosion resistance
• Piston rod made of high-alloy steel with hard chrome finish
• Operating pressure range 1 to 12 bar, temperature range -20°C to +80°C
• Double-acting pneumatic cylinder with 50 mm bore and 100 mm stroke

Technical Specifications

Version & Model Difference

The DNC series from Festo includes various cushioning types: PPV (adjustable pneumatic cushioning), PPS (self-adjusting pneumatic cushioning), and P (no cushioning). The 159590 model specifically has PPV cushioning, which allows manual adjustment of the cushioning effect via screws at both ends. Other versions may have different stroke lengths or bore sizes. The DNC-50-100-PPV-A is the standard version with a 50 mm bore and 100 mm stroke. There are also variants with through piston rod (DNC-50-100-PPV-A-KP) or with non-rotating piston rod (DNC-50-100-PPV-A-KS). The basic version is suitable for most applications, while the variants are used where additional guidance or force transmission from both sides is required.
