Eaton Medium-voltage current-limiting fuse 5AHLE-125A
Eaton
Eaton Medium-voltage current-limiting fuse 5AHLE-125A
Home / Fuses / Medium-Voltage Fuses / Eaton 5AHLE-125A Need Eaton 5AHLE-125A? Medium-voltage current-limiting fuse for Medium-voltage transformer and capacitor…
Specifications
| Brand | Eaton |
|---|---|
| Model Number | 5AHLE-125A |
| Official Product Name | HLE E-Rated current-limiting fuse |
| Applicable System | Medium-voltage transformer and capacitor protection |
| Product Type | Medium-voltage current-limiting fuse |
| Equivalent Standard | IEEE C37.40 / C37.42 (E-Rated) |
| Product Status | Active |
| Lifecycle note | Commercialized |
| Rated voltage | 5.5 kV |
| Interrupting rating | 63 kA |
| Dimensions | 76 mm diameter x 404 mm length (approx. 15.9 in x 15.88 in) |
| Mounting | Contact supplier for exact specifications |
| Type | E-Rated (HLE series) |
| Rated current | 125 A |
Product Description
Basic Product Information
- Current-limiting design limits fault energy
- High 63 kA interrupting rating
- durable porcelain/insulating body for 5.5 kV duty
- E-Rated for transformer and capacitor bank protection
Technical Specifications
Version & Model Difference
- ['5AHLE-125A is the 125 A, 5.5 kV HLE E-Rated fuse', '5HLE-125E / 5AHLE-125E are closely related E-Rated variants (suffix difference)', 'Other HLE ratings cover different current and voltage classes']
Application Scenarios
- Transformer primary protection
- Capacitor bank protection
- Medium-voltage distribution fault limiting
