ABB Control Board 3BHB030310R0001
Home > Products > ABB > Control Boards Need ABB 3BHB030310R0001? Control Board for ABB Symphony Melody, Advant OCS. Supplied with full traceability an…
Estimated market price — final quote depends on stock, condition and shipping.
Specifications
| Brand | ABB |
|---|---|
| Model Number | 3BHB030310R0001 |
| Official Product Name | PCD230A Control Board |
| Applicable System | ABB Symphony Melody, Advant OCS |
| Product Type | Control Board |
| Equivalent Standard | IEC 61131-2 |
| Product Status | In Stock |
| Memory | 4 MB Flash, 8 MB RAM |
| Communication Interfaces | 2x RS-232, 1x RS-485, PROFIBUS DP |
| Power Supply | 24 V DC ±20% |
| Power Consumption | Max 10 W |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H x W x D) | 233 mm x 45 mm x 200 mm |
| Weight | 0.5 kg |
| MTBF | > 100,000 hours |
| Processor | 32-bit RISC, 100 MHz |
Product Description
This board is part of the PCD230 series, known for its reliability and precision in controlling complex processes. It is commonly used in power generation, marine, and heavy industrial applications where robust and accurate control is essential. The PCD230A features a powerful processor with fast execution times, enabling real-time control of critical processes. It supports multiple communication protocols, including PROFIBUS and Modbus, allowing seamless integration into existing automation networks. The board is designed to operate in harsh environments, with a wide temperature range and high immunity to electromagnetic interference. This control board is a genuine ABB product, ensuring compatibility and reliability. It is typically used as a replacement or upgrade in ABB's Symphony Melody and Advant OCS systems. With its advanced features and robust design, the PCD230A is an ideal choice for industries that demand high availability and precise control. The ABB 3BHB030310R0001 PCD230A is a high-performance control board designed for use in ABB's advanced industrial automation systems.
Basic Product Information
- Supports PROFIBUS and Modbus communication protocols
- Wide operating temperature range (-25°C to +70°C)
- Robust design with high EMC immunity
- Compatible with ABB Symphony Melody and Advant OCS systems
- High-speed processor for real-time control
Technical Specifications
Version & Model Difference
The PCD230A (3BHB030310R0001) is an enhanced version of the earlier PCD230. It features a faster processor and increased memory capacity compared to the original PCD230. The 'A' suffix indicates the latest revision with improved EMC performance and updated firmware. It is backward compatible with existing PCD230 installations, but requires the latest software version for full functionality.
Application Scenarios
- ABB UNS 0017A-P Firing Board (SCR Trigger) for UNITROL 5000/6000 Excitation
- ABB KS D211B Input Coupling Unit (ICU) – UNITROL 6000
- ABB M35 UNS4017A-E Var. 633 Thyristor Packet (3BHE026955R0633)
- ABB SDCS-PIN-51-COAT Power Interface Board (3ADT220090R0006) – DCS800
- ABB PS 1500V 125A - 1500 V / 125 A Protection and Switching Device
- ABB FSCA-01 RS-485 Modbus-RTU Adapter Module
- ABB CCM 6080 / UC D240 A01 (3BHE022287R0001) Controller Board
- ABB CP-S.1 24/5.0 Switch Mode Power Supply 24V DC 5A 120W
Compatible Systems
ACS6000 Power Unit Stack, ACS6000 Gate Driver Boards, ACS6000 Control & Power Supply Units, MV drive auxiliary spare parts
Replacement
3BHB030310R0001 = 5SHY4045L0006, the official unique designation of this IGCT press-pack module for ACS6000. Not to be confused with the UNS0881A-P series (Unitrol 6000 generator excitation CPU board, part number 3BHB006338R0001) — different product family, cannot interchange. GVC7XX series are separate gate-driver board codes, not aliases for this 3BHB030310R0001.
