3ABD10078278 | CP430T-ETH | ABB CP400 Compact HMI Series | 5.7-inch Ethernet TFT Touch Operator Interface
Brand: ABB | Model: 3ABD10078278 | SKU: 3ABD10078278
The ABB CP430T (3ABD10078278) is a compact Ethernet-enabled 5.7-inch industrial touchscreen control panel built on the CP400 modular HMI platform. Designed for localized process monitoring, operator command input, alarm visualization, recipe management and drive parameter tuning within discrete manufacturing, process and infrastructure automation systems. Equipped with high-contrast 320x240 color TFT resistive touch display plus 5 physical function keys. Integrated multi-port communication: 10/100Mbps Ethernet (RJ45), RS232, RS485 and USB host, supporting Modbus TCP/IP, Modbus RTU, ABB AC500 native driver, and ABB Drive API. Front panel IP65/NEMA 4X rated. Core Functions: Real-time graphical visualization, dual-input operator control, multi-tier alarm management, recipe storage with USB export/import, native ABB ACS drive diagnostic, local trend plotting, remote Ethernet access for project upload/download.
Interested in this product?
Contact us for pricing and availability:
Technical Specifications
| Part Number | 3ABD10078278 |
| Type Code | CP430T-ETH |
| Display | 5.7 inch Color TFT LCD, 64K colors |
| Resolution | 320 x 240 pixels (QVGA) |
| Touch | 4-wire analog resistive, glove-operable |
| Physical Keys | 5 function keys + 1 menu key |
| Brightness | 300 cd/sq m |
| Backlight Life | 60,000 hours at 25C |
| CPU | 32-bit embedded RISC |
| RAM/Flash | 16 MB RAM / 4 MB Flash |
| Battery SRAM | 512 KB, 30-day data retention |
| Ethernet | 1x RJ45 10/100BASE-T |
| Serial | 1x RS232, 1x RS485 |
| USB | 1x USB Host Type A |
| Protocols | Modbus TCP/IP, Modbus RTU, ABB AC500, ABB Drive API |
| Supply Voltage | 24 V DC (19.2 to 28.8 VDC) |
| Power | Less than 10 W |
| Front Protection | IP65 / NEMA 4X |
| Operating Temp | 0 to 50 C |
| Dimensions | 195 x 145 x 60 mm |
| Weight | 0.86 kg |
| Certifications | CE, cULus, UL 508, RoHS |
Compatible Systems
ABB AC500 PLC; ABB ACS low/medium voltage drives; ABB S800 remote I/O; Modbus RTU/TCP third-party controllers; CP400Soft configuration software
Replacement / Cross-Reference
Direct replacement for all CP430T variants. Battery replacement required every 2-3 years.
